| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_003T01_9000004754_32989cztM0_level2.evt | modeM0/AS1C07_003T01_9000004754_32989cztM0_level2_quad_clean.evt |
| Size (bytes) | 431,023,680 | 76,942,080 |
| Size | 411.1 MB | 73.4 MB |
| Events in quadrant A | 2,555,478 | 511,194 |
| Events in quadrant B | 3,040,141 | 521,670 |
| Events in quadrant C | 2,692,020 | 482,329 |
| Events in quadrant D | 4,419,272 | 456,941 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 104 | 0 |
| B | 0 | 104 | 0 |
| C | 0 | 104 | 0 |
| D | 0 | 104 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31 | 0 |
| B | 0 | 31 | 0 |
| C | 0 | 31 | 0 |
| D | 0 | 32 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10572 | 3 |
| B | 0 | 12051 | 2 |
| C | 0 | 11083 | 2 |
| D | 0 | 16617 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5106 | 10 | 0.195848% |
| B | 5106 | 136 | 2.663533% |
| C | 5106 | 116 | 2.271837% |
| D | 5106 | 227 | 4.445750% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7199 | 5107 | 3 | 3 | 0.04% | 0.06% |  |
| B | 7199 | 5107 | 79 | 79 | 1.10% | 1.55% |  |
| C | 7199 | 5107 | 42 | 42 | 0.58% | 0.82% |  |
| D | 7199 | 5107 | 232 | 232 | 3.22% | 4.54% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 227 | 47543 | 369.76 | 641 | 630 | 126.9 |
| A | 9 | 143 | 28867 | 222.56 | 641 | 630 | 126.9 |
| A | 13 | 254 | 9005 | 66.01 | 641 | 630 | 126.9 |
| B | 5 | 172 | 340518 | 2807.93 | 640 | 626 | 121.0 |
| B | 0 | 197 | 85819 | 703.8 | 640 | 626 | 121.0 |
| B | 0 | 229 | 42484 | 345.8 | 640 | 626 | 121.0 |
| C | 0 | 10 | 233720 | 1651.95 | 610 | 616 | 141.1 |
| C | 9 | 187 | 33243 | 231.22 | 610 | 616 | 141.1 |
| C | 14 | 67 | 20364 | 139.95 | 610 | 616 | 141.1 |
| D | 12 | 227 | 787622 | 5015.78 | 599 | 588 | 156.9 |
| D | 8 | 195 | 667864 | 4252.56 | 599 | 588 | 156.9 |
| D | 2 | 250 | 515405 | 3280.94 | 599 | 588 | 156.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
