| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_008T06_9000004762_33114cztM0_level2.evt | modeM0/AS1A11_008T06_9000004762_33114cztM0_level2_quad_clean.evt |
| Size (bytes) | 573,926,400 | 66,764,160 |
| Size | 547.3 MB | 63.7 MB |
| Events in quadrant A | 2,653,214 | 435,478 |
| Events in quadrant B | 3,417,669 | 425,795 |
| Events in quadrant C | 3,369,430 | 427,340 |
| Events in quadrant D | 7,557,315 | 336,026 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 32 | 0 |
| B | 0 | 32 | 0 |
| C | 0 | 32 | 0 |
| D | 0 | 32 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11416 | 3 |
| B | 0 | 13535 | 2 |
| C | 0 | 13630 | 2 |
| D | 0 | 26415 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5671 | 8 | 0.141069% |
| B | 5671 | 220 | 3.879386% |
| C | 5671 | 102 | 1.798625% |
| D | 5671 | 1392 | 24.545935% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8806 | 5673 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8806 | 5673 | 143 | 143 | 1.62% | 2.52% |  |
| C | 8806 | 5673 | 72 | 72 | 0.82% | 1.27% |  |
| D | 8806 | 5673 | 1226 | 1226 | 13.92% | 21.61% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 10542 | 71.55 | 684 | 670 | 138.0 |
| A | 13 | 6 | 9218 | 61.96 | 684 | 670 | 138.0 |
| A | 3 | 137 | 6474 | 42.07 | 684 | 670 | 138.0 |
| B | 5 | 172 | 594939 | 4599.94 | 671 | 652 | 129.2 |
| B | 0 | 230 | 31769 | 240.85 | 671 | 652 | 129.2 |
| B | 4 | 81 | 23378 | 175.9 | 671 | 652 | 129.2 |
| C | 7 | 221 | 492453 | 3191.52 | 658 | 662 | 154.1 |
| C | 0 | 10 | 146787 | 948.29 | 658 | 662 | 154.1 |
| C | 8 | 111 | 104821 | 675.95 | 658 | 662 | 154.1 |
| D | 7 | 223 | 2822103 | 19674.41 | 592 | 579 | 143.4 |
| D | 8 | 195 | 825144 | 5749.67 | 592 | 579 | 143.4 |
| D | 2 | 249 | 328112 | 2283.88 | 592 | 579 | 143.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
