| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_096T01_9000004766_33134cztM0_level2.evt | modeM0/AS1A11_096T01_9000004766_33134cztM0_level2_quad_clean.evt |
| Size (bytes) | 608,351,040 | 59,339,520 |
| Size | 580.2 MB | 56.6 MB |
| Events in quadrant A | 2,705,933 | 380,763 |
| Events in quadrant B | 4,012,328 | 368,048 |
| Events in quadrant C | 3,277,723 | 363,568 |
| Events in quadrant D | 8,081,334 | 324,735 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 106 | 0 |
| B | 0 | 106 | 0 |
| C | 0 | 106 | 0 |
| D | 0 | 106 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11050 | 3 |
| B | 0 | 15300 | 2 |
| C | 0 | 12891 | 2 |
| D | 0 | 27628 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24 | 0 |
| B | 0 | 24 | 0 |
| C | 0 | 24 | 0 |
| D | 0 | 25 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5122 | 13 | 0.253807% |
| B | 5122 | 388 | 7.575166% |
| C | 5122 | 188 | 3.670441% |
| D | 5122 | 1606 | 31.354939% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7245 | 5123 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7245 | 5123 | 216 | 216 | 2.98% | 4.22% |  |
| C | 7245 | 5123 | 130 | 130 | 1.79% | 2.54% |  |
| D | 7245 | 5123 | 1454 | 1454 | 20.07% | 28.38% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 6 | 16188 | 113.22 | 695 | 686 | 136.9 |
| A | 13 | 254 | 9926 | 67.48 | 695 | 686 | 136.9 |
| A | 0 | 226 | 6078 | 39.38 | 695 | 686 | 136.9 |
| B | 5 | 172 | 714379 | 5739.14 | 670 | 657 | 124.4 |
| B | 0 | 219 | 283080 | 2271.01 | 670 | 657 | 124.4 |
| B | 0 | 189 | 178971 | 1433.85 | 670 | 657 | 124.4 |
| C | 0 | 10 | 312471 | 2131.45 | 643 | 650 | 146.3 |
| C | 7 | 221 | 312049 | 2128.56 | 643 | 650 | 146.3 |
| C | 9 | 187 | 51270 | 346.01 | 643 | 650 | 146.3 |
| D | 8 | 195 | 2044689 | 14768.57 | 568 | 556 | 138.4 |
| D | 2 | 249 | 1130464 | 8163.43 | 568 | 556 | 138.4 |
| D | 14 | 52 | 604532 | 4363.64 | 568 | 556 | 138.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
