| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_096T01_9000004766_33161cztM0_level2.evt | modeM0/AS1A11_096T01_9000004766_33161cztM0_level2_quad_clean.evt |
| Size (bytes) | 2,608,669,440 | 337,273,920 |
| Size | 2.4 GB | 321.6 MB |
| Events in quadrant A | 13,996,003 | 2,101,507 |
| Events in quadrant B | 20,433,814 | 2,092,504 |
| Events in quadrant C | 14,968,391 | 2,064,519 |
| Events in quadrant D | 27,629,109 | 1,936,298 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 598 | 0 |
| B | 0 | 598 | 0 |
| C | 0 | 598 | 0 |
| D | 0 | 598 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 60449 | 7 |
| B | 0 | 80004 | 6 |
| C | 0 | 63056 | 6 |
| D | 0 | 103133 | 6 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 88 | 0 |
| B | 0 | 88 | 0 |
| C | 0 | 88 | 0 |
| D | 0 | 89 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 29395 | 39 | 0.132676% |
| B | 29395 | 1858 | 6.320803% |
| C | 29395 | 274 | 0.932131% |
| D | 29395 | 1481 | 5.038272% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 44952 | 29401 | 1 | 1 | 0.00% | 0.00% |  |
| B | 44952 | 29401 | 981 | 981 | 2.18% | 3.34% |  |
| C | 44952 | 29401 | 211 | 211 | 0.47% | 0.72% |  |
| D | 44952 | 29401 | 1159 | 1159 | 2.58% | 3.94% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 254 | 128785 | 177.04 | 3569 | 3497 | 707.7 |
| A | 13 | 254 | 53947 | 71.29 | 3569 | 3497 | 707.7 |
| A | 13 | 6 | 42867 | 55.63 | 3569 | 3497 | 707.7 |
| B | 5 | 172 | 2735793 | 4216.74 | 3465 | 3386 | 648.0 |
| B | 0 | 219 | 1711996 | 2636.78 | 3465 | 3386 | 648.0 |
| B | 5 | 200 | 847748 | 1303.05 | 3465 | 3386 | 648.0 |
| C | 0 | 10 | 743774 | 934.73 | 3449 | 3478 | 792.0 |
| C | 1 | 241 | 320414 | 400.18 | 3449 | 3478 | 792.0 |
| C | 14 | 67 | 136252 | 167.65 | 3449 | 3478 | 792.0 |
| D | 8 | 195 | 6633775 | 7647.14 | 3406 | 3332 | 867.0 |
| D | 2 | 249 | 1667375 | 1919.2 | 3406 | 3332 | 867.0 |
| D | 2 | 250 | 1640205 | 1887.87 | 3406 | 3332 | 867.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
