| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_080T02_9000004768_33168cztM0_level2.evt | modeM0/AS1A11_080T02_9000004768_33168cztM0_level2_quad_clean.evt |
| Size (bytes) | 481,694,400 | 90,973,440 |
| Size | 459.4 MB | 86.8 MB |
| Events in quadrant A | 2,706,510 | 596,184 |
| Events in quadrant B | 3,503,603 | 597,532 |
| Events in quadrant C | 2,972,724 | 592,512 |
| Events in quadrant D | 5,002,224 | 553,878 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 15 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 120 | 0 |
| B | 0 | 120 | 0 |
| C | 0 | 120 | 0 |
| D | 0 | 120 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12033 | 3 |
| B | 0 | 14439 | 2 |
| C | 0 | 12869 | 2 |
| D | 0 | 19041 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5940 | 7 | 0.117845% |
| B | 5940 | 208 | 3.501684% |
| C | 5940 | 100 | 1.683502% |
| D | 5940 | 366 | 6.161616% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7253 | 5941 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7253 | 5941 | 95 | 95 | 1.31% | 1.60% |  |
| C | 7253 | 5941 | 64 | 64 | 0.88% | 1.08% |  |
| D | 7253 | 5941 | 303 | 303 | 4.18% | 5.10% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 9720 | 64.45 | 694 | 680 | 140.3 |
| A | 13 | 210 | 8940 | 58.89 | 694 | 680 | 140.3 |
| A | 13 | 6 | 7838 | 51.04 | 694 | 680 | 140.3 |
| B | 5 | 172 | 521476 | 3935.91 | 680 | 663 | 132.3 |
| B | 0 | 197 | 105257 | 790.44 | 680 | 663 | 132.3 |
| B | 0 | 219 | 42172 | 313.69 | 680 | 663 | 132.3 |
| C | 0 | 10 | 220327 | 1414.41 | 667 | 672 | 155.3 |
| C | 1 | 241 | 91546 | 585.16 | 667 | 672 | 155.3 |
| C | 9 | 187 | 22391 | 139.85 | 667 | 672 | 155.3 |
| D | 8 | 195 | 892939 | 5294.8 | 652 | 637 | 168.5 |
| D | 2 | 250 | 583572 | 3459.06 | 652 | 637 | 168.5 |
| D | 10 | 203 | 321642 | 1904.8 | 652 | 637 | 168.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
