| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_080T02_9000004768_33192cztM0_level2.evt | modeM0/AS1A11_080T02_9000004768_33192cztM0_level2_quad_clean.evt |
| Size (bytes) | 479,298,240 | 57,294,720 |
| Size | 457.1 MB | 54.6 MB |
| Events in quadrant A | 2,596,992 | 356,626 |
| Events in quadrant B | 4,347,654 | 343,643 |
| Events in quadrant C | 2,926,232 | 349,302 |
| Events in quadrant D | 4,308,170 | 336,354 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25 | 0 |
| B | 0 | 25 | 0 |
| C | 0 | 25 | 0 |
| D | 0 | 26 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 100 | 0 |
| B | 0 | 100 | 0 |
| C | 0 | 100 | 0 |
| D | 0 | 100 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10454 | 14 |
| B | 0 | 16221 | 20 |
| C | 0 | 11505 | 7 |
| D | 0 | 16574 | 10 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4972 | 8 | 0.160901% |
| B | 4973 | 415 | 8.345063% |
| C | 4975 | 93 | 1.869347% |
| D | 4975 | 85 | 1.708543% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7102 | 4977 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7102 | 4979 | 269 | 269 | 3.79% | 5.40% |  |
| C | 7102 | 4978 | 67 | 67 | 0.94% | 1.35% |  |
| D | 7102 | 4980 | 66 | 66 | 0.93% | 1.33% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 31 | 26506 | 197.53 | 661 | 650 | 130.9 |
| A | 13 | 254 | 8351 | 58.83 | 661 | 650 | 130.9 |
| A | 13 | 6 | 8286 | 58.34 | 661 | 650 | 130.9 |
| B | 5 | 172 | 565052 | 4760.17 | 636 | 623 | 118.6 |
| B | 5 | 31 | 404115 | 3402.89 | 636 | 623 | 118.6 |
| B | 0 | 219 | 294008 | 2474.29 | 636 | 623 | 118.6 |
| C | 0 | 10 | 168815 | 1161.95 | 637 | 645 | 144.7 |
| C | 9 | 187 | 138807 | 954.61 | 637 | 645 | 144.7 |
| C | 1 | 241 | 49475 | 337.38 | 637 | 645 | 144.7 |
| D | 8 | 195 | 922434 | 5539.81 | 642 | 629 | 166.4 |
| D | 10 | 203 | 199697 | 1196.35 | 642 | 629 | 166.4 |
| D | 2 | 250 | 190099 | 1138.67 | 642 | 629 | 166.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
