| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_067T01_9000004774_33232cztM0_level2.evt | modeM0/AS1A10_067T01_9000004774_33232cztM0_level2_quad_clean.evt |
| Size (bytes) | 562,962,240 | 70,827,840 |
| Size | 536.9 MB | 67.5 MB |
| Events in quadrant A | 2,607,569 | 456,589 |
| Events in quadrant B | 5,041,401 | 457,836 |
| Events in quadrant C | 4,201,195 | 424,821 |
| Events in quadrant D | 4,830,979 | 424,274 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 22 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 110 | 0 |
| B | 0 | 110 | 0 |
| C | 0 | 110 | 0 |
| D | 0 | 110 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10993 | 3 |
| B | 0 | 18586 | 2 |
| C | 0 | 16064 | 2 |
| D | 0 | 18112 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5446 | 6 | 0.110173% |
| B | 5446 | 762 | 13.991921% |
| C | 5446 | 303 | 5.563716% |
| D | 5446 | 150 | 2.754315% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7238 | 5447 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7238 | 5447 | 559 | 559 | 7.72% | 10.26% |  |
| C | 7238 | 5447 | 270 | 270 | 3.73% | 4.96% |  |
| D | 7238 | 5447 | 113 | 113 | 1.56% | 2.07% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 6 | 10693 | 74.78 | 670 | 658 | 134.2 |
| A | 13 | 254 | 8744 | 60.25 | 670 | 658 | 134.2 |
| A | 15 | 47 | 8598 | 59.16 | 670 | 658 | 134.2 |
| B | 5 | 172 | 1905851 | 16014.15 | 619 | 605 | 119.0 |
| B | 4 | 170 | 550935 | 4625.69 | 619 | 605 | 119.0 |
| B | 0 | 245 | 35411 | 292.55 | 619 | 605 | 119.0 |
| C | 14 | 254 | 523282 | 3619.67 | 629 | 636 | 144.4 |
| C | 10 | 49 | 439843 | 3041.8 | 629 | 636 | 144.4 |
| C | 15 | 208 | 397773 | 2750.43 | 629 | 636 | 144.4 |
| D | 8 | 195 | 1445985 | 9048.0 | 645 | 625 | 159.7 |
| D | 10 | 203 | 218853 | 1366.11 | 645 | 625 | 159.7 |
| D | 2 | 250 | 187968 | 1172.77 | 645 | 625 | 159.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
