| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_046T01_9000004776_33249cztM0_level2.evt | modeM0/AS1A11_046T01_9000004776_33249cztM0_level2_quad_clean.evt |
| Size (bytes) | 496,820,160 | 110,260,800 |
| Size | 473.8 MB | 105.2 MB |
| Events in quadrant A | 4,542,301 | 765,952 |
| Events in quadrant B | 3,491,511 | 757,913 |
| Events in quadrant C | 2,724,971 | 745,882 |
| Events in quadrant D | 3,947,627 | 717,626 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 102 | 0 |
| B | 0 | 102 | 0 |
| C | 0 | 102 | 0 |
| D | 0 | 102 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17019 | 3 |
| B | 0 | 13432 | 2 |
| C | 0 | 11100 | 2 |
| D | 0 | 15384 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 21 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5023 | 228 | 4.539120% |
| B | 5023 | 273 | 5.434999% |
| C | 5023 | 42 | 0.836154% |
| D | 5023 | 33 | 0.656978% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7086 | 5024 | 150 | 150 | 2.12% | 2.99% |  |
| B | 7086 | 5024 | 200 | 200 | 2.82% | 3.98% |  |
| C | 7086 | 5024 | 38 | 38 | 0.54% | 0.76% |  |
| D | 7086 | 5024 | 20 | 20 | 0.28% | 0.40% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 2019208 | 15839.58 | 649 | 638 | 127.4 |
| A | 13 | 6 | 11493 | 85.18 | 649 | 638 | 127.4 |
| A | 13 | 254 | 8747 | 63.63 | 649 | 638 | 127.4 |
| B | 5 | 172 | 759545 | 6605.33 | 625 | 612 | 114.9 |
| B | 0 | 219 | 71484 | 616.83 | 625 | 612 | 114.9 |
| B | 4 | 170 | 68037 | 586.83 | 625 | 612 | 114.9 |
| C | 0 | 10 | 185631 | 1329.26 | 616 | 621 | 139.2 |
| C | 10 | 49 | 111892 | 799.46 | 616 | 621 | 139.2 |
| C | 14 | 254 | 9065 | 60.67 | 616 | 621 | 139.2 |
| D | 8 | 195 | 1228599 | 7923.12 | 634 | 617 | 155.0 |
| D | 2 | 250 | 72210 | 461.93 | 634 | 617 | 155.0 |
| D | 2 | 120 | 43699 | 277.97 | 634 | 617 | 155.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
