| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_072T01_9000004780_33458cztM0_level2.evt | modeM0/AS1T04_072T01_9000004780_33458cztM0_level2_quad_clean.evt |
| Size (bytes) | 520,992,000 | 60,733,440 |
| Size | 496.9 MB | 57.9 MB |
| Events in quadrant A | 2,738,986 | 363,449 |
| Events in quadrant B | 3,791,977 | 359,873 |
| Events in quadrant C | 3,498,666 | 354,997 |
| Events in quadrant D | 5,341,928 | 340,939 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12081 | 3 |
| B | 0 | 15072 | 2 |
| C | 0 | 14024 | 2 |
| D | 0 | 19950 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 19 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6006 | 9 | 0.149850% |
| B | 6006 | 212 | 3.529804% |
| C | 6006 | 159 | 2.647353% |
| D | 6006 | 98 | 1.631702% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7318 | 6007 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7318 | 6007 | 145 | 145 | 1.98% | 2.41% |  |
| C | 7318 | 6007 | 112 | 112 | 1.53% | 1.86% |  |
| D | 7318 | 6007 | 76 | 76 | 1.04% | 1.27% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 6 | 16423 | 111.99 | 702 | 688 | 140.5 |
| A | 13 | 254 | 10398 | 69.11 | 702 | 688 | 140.5 |
| A | 3 | 137 | 6903 | 44.23 | 702 | 688 | 140.5 |
| B | 5 | 172 | 585549 | 4422.57 | 686 | 666 | 132.2 |
| B | 5 | 255 | 260041 | 1961.25 | 686 | 666 | 132.2 |
| B | 4 | 170 | 57592 | 430.44 | 686 | 666 | 132.2 |
| C | 1 | 23 | 414653 | 2677.15 | 668 | 672 | 154.6 |
| C | 15 | 214 | 256938 | 1657.23 | 668 | 672 | 154.6 |
| C | 0 | 10 | 94780 | 608.58 | 668 | 672 | 154.6 |
| D | 8 | 195 | 2094990 | 11664.47 | 671 | 655 | 179.5 |
| D | 2 | 250 | 248943 | 1382.85 | 671 | 655 | 179.5 |
| D | 13 | 249 | 87333 | 482.76 | 671 | 655 | 179.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
