| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_058T15_9000004786_33344cztM0_level2.evt | modeM0/AS1A10_058T15_9000004786_33344cztM0_level2_quad_clean.evt |
| Size (bytes) | 904,930,560 | 110,658,240 |
| Size | 863.0 MB | 105.5 MB |
| Events in quadrant A | 4,631,447 | 695,461 |
| Events in quadrant B | 6,330,483 | 678,334 |
| Events in quadrant C | 6,203,627 | 666,221 |
| Events in quadrant D | 9,585,720 | 637,947 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20028 | 3 |
| B | 0 | 25179 | 2 |
| C | 0 | 24376 | 2 |
| D | 0 | 35255 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 21 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 194 | 0 |
| B | 0 | 194 | 0 |
| C | 0 | 194 | 0 |
| D | 0 | 194 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 9713 | 20 | 0.205910% |
| B | 9713 | 482 | 4.962421% |
| C | 9713 | 297 | 3.057758% |
| D | 9713 | 586 | 6.033151% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 11054 | 9714 | 1 | 1 | 0.01% | 0.01% |  |
| B | 11054 | 9714 | 222 | 222 | 2.01% | 2.29% |  |
| C | 11054 | 9714 | 297 | 297 | 2.69% | 3.06% |  |
| D | 11054 | 9714 | 405 | 405 | 3.66% | 4.17% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 16 | 96091 | 408.25 | 1156 | 1132 | 232.6 |
| A | 15 | 169 | 36050 | 150.12 | 1156 | 1132 | 232.6 |
| A | 12 | 194 | 23266 | 95.16 | 1156 | 1132 | 232.6 |
| B | 0 | 219 | 1073978 | 4902.45 | 1135 | 1103 | 218.8 |
| B | 5 | 172 | 496105 | 2261.89 | 1135 | 1103 | 218.8 |
| B | 4 | 170 | 109915 | 497.21 | 1135 | 1103 | 218.8 |
| C | 15 | 208 | 719027 | 2809.88 | 1101 | 1108 | 255.5 |
| C | 15 | 214 | 412058 | 1608.43 | 1101 | 1108 | 255.5 |
| C | 1 | 23 | 365407 | 1425.84 | 1101 | 1108 | 255.5 |
| D | 8 | 195 | 2696367 | 9321.2 | 1094 | 1068 | 289.2 |
| D | 12 | 218 | 718442 | 2480.91 | 1094 | 1068 | 289.2 |
| D | 14 | 173 | 566549 | 1955.61 | 1094 | 1068 | 289.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
