| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_064T02_9000004788_33383cztM0_level2.evt | modeM0/AS1A10_064T02_9000004788_33383cztM0_level2_quad_clean.evt |
| Size (bytes) | 560,632,320 | 60,148,800 |
| Size | 534.7 MB | 57.4 MB |
| Events in quadrant A | 2,496,672 | 375,019 |
| Events in quadrant B | 4,218,416 | 378,659 |
| Events in quadrant C | 3,015,143 | 369,944 |
| Events in quadrant D | 6,886,213 | 322,493 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24 | 0 |
| B | 0 | 24 | 0 |
| C | 0 | 24 | 0 |
| D | 0 | 25 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10740 | 3 |
| B | 0 | 15892 | 2 |
| C | 0 | 11849 | 2 |
| D | 0 | 24198 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 110 | 0 |
| B | 0 | 110 | 0 |
| C | 0 | 110 | 0 |
| D | 0 | 110 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5348 | 3 | 0.056096% |
| B | 5348 | 604 | 11.293942% |
| C | 5348 | 67 | 1.252805% |
| D | 5348 | 958 | 17.913239% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7081 | 5349 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7080 | 5348 | 341 | 341 | 4.82% | 6.38% |  |
| C | 7081 | 5349 | 58 | 58 | 0.82% | 1.08% |  |
| D | 7081 | 5348 | 923 | 923 | 13.03% | 17.26% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 8627 | 61.9 | 641 | 630 | 129.2 |
| A | 10 | 223 | 8313 | 59.47 | 641 | 630 | 129.2 |
| A | 13 | 6 | 5953 | 41.2 | 641 | 630 | 129.2 |
| B | 5 | 172 | 760327 | 6477.38 | 613 | 597 | 117.3 |
| B | 0 | 219 | 639364 | 5446.06 | 613 | 597 | 117.3 |
| B | 5 | 200 | 183167 | 1556.57 | 613 | 597 | 117.3 |
| C | 15 | 214 | 231784 | 1611.91 | 619 | 625 | 143.4 |
| C | 14 | 254 | 131981 | 915.97 | 619 | 625 | 143.4 |
| C | 0 | 10 | 131262 | 910.96 | 619 | 625 | 143.4 |
| D | 8 | 195 | 1654074 | 11190.18 | 585 | 568 | 147.8 |
| D | 2 | 250 | 1119407 | 7571.8 | 585 | 568 | 147.8 |
| D | 1 | 52 | 722569 | 4886.18 | 585 | 568 | 147.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
