| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_064T02_9000004788_33394cztM0_level2.evt | modeM0/AS1A10_064T02_9000004788_33394cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,498,705,920 | 260,516,160 |
| Size | 1.4 GB | 248.4 MB |
| Events in quadrant A | 7,874,749 | 1,779,720 |
| Events in quadrant B | 10,889,730 | 1,649,000 |
| Events in quadrant C | 10,306,343 | 1,727,050 |
| Events in quadrant D | 15,189,353 | 1,580,537 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 61 | 0 |
| B | 0 | 61 | 0 |
| C | 0 | 61 | 0 |
| D | 0 | 62 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 34055 | 5 |
| B | 0 | 43544 | 4 |
| C | 0 | 40605 | 4 |
| D | 0 | 56856 | 4 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 342 | 0 |
| B | 0 | 342 | 0 |
| C | 0 | 342 | 0 |
| D | 0 | 342 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 16727 | 16 | 0.095654% |
| B | 16727 | 1770 | 10.581694% |
| C | 16727 | 610 | 3.646799% |
| D | 16727 | 1325 | 7.921325% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 26234 | 16731 | 0 | 0 | 0.00% | 0.00% |  |
| B | 26233 | 16730 | 492 | 492 | 1.88% | 2.94% |  |
| C | 26234 | 16731 | 527 | 527 | 2.01% | 3.15% |  |
| D | 26234 | 16731 | 1220 | 1220 | 4.65% | 7.29% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 100474 | 248.4 | 2010 | 1973 | 396.5 |
| A | 13 | 254 | 25702 | 59.84 | 2010 | 1973 | 396.5 |
| A | 3 | 137 | 18687 | 42.15 | 2010 | 1973 | 396.5 |
| B | 5 | 172 | 1387550 | 4021.18 | 1851 | 1806 | 344.6 |
| B | 12 | 1 | 877791 | 2541.95 | 1851 | 1806 | 344.6 |
| B | 5 | 255 | 329878 | 952.01 | 1851 | 1806 | 344.6 |
| C | 1 | 23 | 1176384 | 2697.59 | 1909 | 1927 | 435.4 |
| C | 0 | 10 | 701773 | 1607.46 | 1909 | 1927 | 435.4 |
| C | 15 | 214 | 698684 | 1600.37 | 1909 | 1927 | 435.4 |
| D | 8 | 195 | 3238050 | 7127.23 | 1862 | 1817 | 454.1 |
| D | 1 | 52 | 1515524 | 3333.67 | 1862 | 1817 | 454.1 |
| D | 13 | 249 | 730200 | 1604.13 | 1862 | 1817 | 454.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
