| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_001T03_9000004790_33404cztM0_level2.evt | modeM0/AS1C07_001T03_9000004790_33404cztM0_level2_quad_clean.evt |
| Size (bytes) | 556,709,760 | 79,315,200 |
| Size | 530.9 MB | 75.6 MB |
| Events in quadrant A | 2,517,521 | 529,480 |
| Events in quadrant B | 4,025,182 | 503,288 |
| Events in quadrant C | 3,391,323 | 523,455 |
| Events in quadrant D | 6,544,155 | 451,361 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 114 | 0 |
| B | 0 | 114 | 0 |
| C | 0 | 114 | 0 |
| D | 0 | 114 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11314 | 2 |
| B | 0 | 15695 | 1 |
| C | 0 | 13592 | 1 |
| D | 0 | 23339 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 24 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5633 | 3 | 0.053258% |
| B | 5633 | 474 | 8.414699% |
| C | 5633 | 242 | 4.296112% |
| D | 5633 | 1246 | 22.119652% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7306 | 5634 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7306 | 5634 | 347 | 347 | 4.75% | 6.16% |  |
| C | 7306 | 5634 | 211 | 211 | 2.89% | 3.75% |  |
| D | 7306 | 5634 | 1142 | 1142 | 15.63% | 20.27% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 9760 | 69.85 | 650 | 638 | 130.6 |
| A | 3 | 137 | 6407 | 44.18 | 650 | 638 | 130.6 |
| A | 13 | 6 | 6013 | 41.16 | 650 | 638 | 130.6 |
| B | 5 | 172 | 1260846 | 10547.17 | 628 | 612 | 119.5 |
| B | 0 | 189 | 95074 | 790.57 | 628 | 612 | 119.5 |
| B | 0 | 245 | 45808 | 378.25 | 628 | 612 | 119.5 |
| C | 4 | 254 | 446182 | 3110.66 | 620 | 624 | 143.2 |
| C | 15 | 214 | 241511 | 1681.75 | 620 | 624 | 143.2 |
| C | 0 | 10 | 128024 | 889.44 | 620 | 624 | 143.2 |
| D | 2 | 250 | 2469707 | 17695.95 | 566 | 550 | 139.5 |
| D | 8 | 195 | 720106 | 5156.91 | 566 | 550 | 139.5 |
| D | 13 | 249 | 419648 | 3003.59 | 566 | 550 | 139.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
