| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_065T01_9000004794_33438cztM0_level2.evt | modeM0/AS1A11_065T01_9000004794_33438cztM0_level2_quad_clean.evt |
| Size (bytes) | 547,179,840 | 71,697,600 |
| Size | 521.8 MB | 68.4 MB |
| Events in quadrant A | 2,548,642 | 486,405 |
| Events in quadrant B | 5,680,571 | 426,933 |
| Events in quadrant C | 2,819,700 | 468,731 |
| Events in quadrant D | 5,172,761 | 426,572 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 104 | 0 |
| B | 0 | 104 | 0 |
| C | 0 | 104 | 0 |
| D | 0 | 104 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10509 | 3 |
| B | 0 | 20247 | 2 |
| C | 0 | 11259 | 2 |
| D | 0 | 18953 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 33 | 0 |
| B | 0 | 33 | 0 |
| C | 0 | 33 | 0 |
| D | 0 | 34 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5169 | 7 | 0.135423% |
| B | 5169 | 1097 | 21.222674% |
| C | 5169 | 65 | 1.257497% |
| D | 5169 | 353 | 6.829174% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7292 | 5170 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7292 | 5170 | 978 | 978 | 13.41% | 18.92% |  |
| C | 7292 | 5170 | 64 | 64 | 0.88% | 1.24% |  |
| D | 7292 | 5170 | 422 | 422 | 5.79% | 8.16% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 47 | 59975 | 463.09 | 640 | 630 | 128.1 |
| A | 13 | 6 | 16960 | 127.43 | 640 | 630 | 128.1 |
| A | 13 | 254 | 8485 | 61.3 | 640 | 630 | 128.1 |
| B | 5 | 172 | 2786183 | 25516.21 | 581 | 568 | 109.2 |
| B | 5 | 255 | 241304 | 2205.14 | 581 | 568 | 109.2 |
| B | 0 | 219 | 191074 | 1745.03 | 581 | 568 | 109.2 |
| C | 15 | 214 | 224803 | 1623.08 | 604 | 608 | 138.1 |
| C | 0 | 10 | 119174 | 858.37 | 604 | 608 | 138.1 |
| C | 1 | 23 | 78308 | 562.52 | 604 | 608 | 138.1 |
| D | 8 | 195 | 1504180 | 10356.64 | 597 | 580 | 145.2 |
| D | 1 | 52 | 945141 | 6506.04 | 597 | 580 | 145.2 |
| D | 2 | 250 | 137380 | 942.26 | 597 | 580 | 145.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
