| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_065T02_9000004796_33443cztM0_level2.evt | modeM0/AS1A11_065T02_9000004796_33443cztM0_level2_quad_clean.evt |
| Size (bytes) | 264,093,120 | 23,670,720 |
| Size | 251.9 MB | 22.6 MB |
| Events in quadrant A | 1,071,037 | 165,823 |
| Events in quadrant B | 1,435,704 | 162,036 |
| Events in quadrant C | 1,189,244 | 161,665 |
| Events in quadrant D | 4,146,706 | 62,937 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 48 | 0 |
| B | 0 | 48 | 0 |
| C | 0 | 48 | 0 |
| D | 0 | 48 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4548 | 2 |
| B | 0 | 5652 | 1 |
| C | 0 | 4799 | 1 |
| D | 0 | 13904 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2257 | 4 | 0.177226% |
| B | 2257 | 76 | 3.367302% |
| C | 2257 | 19 | 0.841825% |
| D | 2257 | 1290 | 57.155516% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3571 | 2258 | 0 | 0 | 0.00% | 0.00% |  |
| B | 3571 | 2258 | 50 | 50 | 1.40% | 2.21% |  |
| C | 3571 | 2258 | 12 | 12 | 0.34% | 0.53% |  |
| D | 3571 | 2258 | 1198 | 1198 | 33.55% | 53.06% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 6 | 4786 | 78.98 | 274 | 268 | 57.2 |
| A | 13 | 254 | 4019 | 65.57 | 274 | 268 | 57.2 |
| A | 14 | 254 | 3013 | 47.99 | 274 | 268 | 57.2 |
| B | 5 | 172 | 258557 | 4765.45 | 267 | 260 | 54.2 |
| B | 4 | 251 | 36026 | 659.86 | 267 | 260 | 54.2 |
| B | 15 | 85 | 29481 | 539.11 | 267 | 260 | 54.2 |
| C | 15 | 214 | 99701 | 1603.27 | 259 | 259 | 62.0 |
| C | 0 | 10 | 39568 | 633.76 | 259 | 259 | 62.0 |
| C | 14 | 254 | 26650 | 425.49 | 259 | 259 | 62.0 |
| D | 1 | 52 | 3034635 | 80706.64 | 146 | 140 | 37.6 |
| D | 8 | 195 | 349073 | 9280.36 | 146 | 140 | 37.6 |
| D | 12 | 218 | 41421 | 1097.93 | 146 | 140 | 37.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
