| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_065T02_9000004796_33446cztM0_level2.evt | modeM0/AS1A11_065T02_9000004796_33446cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,362,424,320 | 234,630,720 |
| Size | 1.3 GB | 223.8 MB |
| Events in quadrant A | 7,433,383 | 1,558,090 |
| Events in quadrant B | 9,031,818 | 1,521,708 |
| Events in quadrant C | 8,162,134 | 1,521,899 |
| Events in quadrant D | 15,574,461 | 1,420,613 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 322 | 0 |
| B | 0 | 322 | 0 |
| C | 0 | 322 | 0 |
| D | 0 | 322 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 55 | 0 |
| B | 0 | 55 | 0 |
| C | 0 | 55 | 0 |
| D | 0 | 55 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 32919 | 5 |
| B | 0 | 37140 | 3 |
| C | 0 | 33788 | 3 |
| D | 0 | 57193 | 3 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 15717 | 25 | 0.159063% |
| B | 15717 | 447 | 2.844054% |
| C | 15717 | 141 | 0.897118% |
| D | 15717 | 1303 | 8.290386% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 21210 | 15722 | 8 | 8 | 0.04% | 0.05% |  |
| B | 21210 | 15722 | 326 | 326 | 1.54% | 2.07% |  |
| C | 21210 | 15722 | 98 | 98 | 0.46% | 0.62% |  |
| D | 21210 | 15722 | 1175 | 1175 | 5.54% | 7.47% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 192 | 329042 | 902.44 | 1816 | 1780 | 362.6 |
| A | 9 | 143 | 32915 | 85.86 | 1816 | 1780 | 362.6 |
| A | 13 | 6 | 28774 | 74.44 | 1816 | 1780 | 362.6 |
| B | 5 | 172 | 1268009 | 3684.31 | 1784 | 1736 | 343.7 |
| B | 5 | 200 | 226208 | 653.12 | 1784 | 1736 | 343.7 |
| B | 0 | 213 | 122685 | 351.91 | 1784 | 1736 | 343.7 |
| C | 15 | 214 | 670605 | 1655.84 | 1747 | 1760 | 403.9 |
| C | 0 | 10 | 272230 | 669.59 | 1747 | 1760 | 403.9 |
| C | 10 | 49 | 190008 | 466.04 | 1747 | 1760 | 403.9 |
| D | 8 | 195 | 4910108 | 11822.27 | 1683 | 1633 | 415.2 |
| D | 12 | 218 | 1060210 | 2549.63 | 1683 | 1633 | 415.2 |
| D | 2 | 250 | 992690 | 2387.0 | 1683 | 1633 | 415.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
