| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_060T01_9000004808_33571cztM0_level2.evt | modeM0/AS1A11_060T01_9000004808_33571cztM0_level2_quad_clean.evt |
| Size (bytes) | 508,913,280 | 50,160,960 |
| Size | 485.3 MB | 47.8 MB |
| Events in quadrant A | 2,587,373 | 297,964 |
| Events in quadrant B | 3,014,668 | 295,566 |
| Events in quadrant C | 4,295,911 | 292,159 |
| Events in quadrant D | 5,160,523 | 266,310 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10916 | 3 |
| B | 0 | 12195 | 2 |
| C | 0 | 16560 | 2 |
| D | 0 | 18940 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 28 | 0 |
| B | 0 | 28 | 0 |
| C | 0 | 28 | 0 |
| D | 0 | 29 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 108 | 0 |
| B | 0 | 108 | 0 |
| C | 0 | 108 | 0 |
| D | 0 | 108 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5225 | 25 | 0.478469% |
| B | 5225 | 133 | 2.545455% |
| C | 5225 | 167 | 3.196172% |
| D | 5225 | 432 | 8.267943% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7048 | 5226 | 19 | 19 | 0.27% | 0.36% |  |
| B | 7048 | 5226 | 107 | 107 | 1.52% | 2.05% |  |
| C | 7048 | 5226 | 142 | 142 | 2.01% | 2.72% |  |
| D | 7048 | 5226 | 417 | 417 | 5.92% | 7.98% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 183315 | 1467.23 | 620 | 608 | 124.5 |
| A | 13 | 254 | 9304 | 69.83 | 620 | 608 | 124.5 |
| A | 3 | 137 | 6171 | 44.67 | 620 | 608 | 124.5 |
| B | 5 | 172 | 517181 | 4397.57 | 615 | 598 | 117.5 |
| B | 5 | 255 | 14695 | 120.0 | 615 | 598 | 117.5 |
| B | 12 | 111 | 14537 | 118.66 | 615 | 598 | 117.5 |
| C | 3 | 233 | 1339841 | 9483.08 | 602 | 608 | 141.2 |
| C | 0 | 10 | 225991 | 1595.93 | 602 | 608 | 141.2 |
| C | 15 | 214 | 222449 | 1570.85 | 602 | 608 | 141.2 |
| D | 8 | 195 | 1367710 | 9451.05 | 587 | 570 | 144.7 |
| D | 2 | 250 | 612121 | 4227.66 | 587 | 570 | 144.7 |
| D | 1 | 47 | 422176 | 2914.56 | 587 | 570 | 144.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
