| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_060T01_9000004808_33596cztM0_level2.evt | modeM0/AS1A11_060T01_9000004808_33596cztM0_level2_quad_clean.evt |
| Size (bytes) | 486,593,280 | 74,226,240 |
| Size | 464.1 MB | 70.8 MB |
| Events in quadrant A | 3,211,861 | 490,905 |
| Events in quadrant B | 4,178,203 | 482,393 |
| Events in quadrant C | 3,154,409 | 473,697 |
| Events in quadrant D | 3,840,009 | 436,792 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12785 | 3 |
| B | 0 | 15735 | 2 |
| C | 0 | 12547 | 2 |
| D | 0 | 15015 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 36 | 0 |
| B | 0 | 36 | 0 |
| C | 0 | 36 | 0 |
| D | 0 | 37 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 106 | 0 |
| B | 0 | 106 | 0 |
| C | 0 | 106 | 0 |
| D | 0 | 106 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5193 | 96 | 1.848642% |
| B | 5193 | 429 | 8.261121% |
| C | 5193 | 68 | 1.309455% |
| D | 5193 | 150 | 2.888504% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7226 | 5194 | 36 | 36 | 0.50% | 0.69% |  |
| B | 7226 | 5194 | 343 | 343 | 4.75% | 6.60% |  |
| C | 7226 | 5194 | 64 | 64 | 0.89% | 1.23% |  |
| D | 7226 | 5194 | 166 | 166 | 2.30% | 3.20% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 678416 | 5227.45 | 652 | 642 | 129.7 |
| A | 13 | 6 | 8987 | 64.36 | 652 | 642 | 129.7 |
| A | 13 | 254 | 8351 | 59.46 | 652 | 642 | 129.7 |
| B | 5 | 172 | 1233703 | 10106.31 | 640 | 625 | 122.0 |
| B | 0 | 213 | 190304 | 1554.61 | 640 | 625 | 122.0 |
| B | 5 | 255 | 80250 | 652.61 | 640 | 625 | 122.0 |
| C | 15 | 214 | 223023 | 1521.54 | 635 | 640 | 146.2 |
| C | 0 | 10 | 196161 | 1337.75 | 635 | 640 | 146.2 |
| C | 3 | 233 | 191160 | 1303.54 | 635 | 640 | 146.2 |
| D | 8 | 195 | 610721 | 4079.01 | 619 | 604 | 149.6 |
| D | 2 | 250 | 240852 | 1606.21 | 619 | 604 | 149.6 |
| D | 1 | 52 | 165171 | 1100.23 | 619 | 604 | 149.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
