| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_088T01_9000004814_33707cztM0_level2.evt | modeM0/AS1T04_088T01_9000004814_33707cztM0_level2_quad_clean.evt |
| Size (bytes) | 94,887,360 | 17,251,200 |
| Size | 90.5 MB | 16.5 MB |
| Events in quadrant A | 669,218 | 111,056 |
| Events in quadrant B | 659,917 | 115,650 |
| Events in quadrant C | 642,671 | 112,959 |
| Events in quadrant D | 833,366 | 107,472 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2575 | 2 |
| B | 0 | 2556 | 1 |
| C | 0 | 2453 | 1 |
| D | 0 | 3203 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 963 | 75 | 7.788162% |
| B | 963 | 55 | 5.711319% |
| C | 963 | 42 | 4.361371% |
| D | 963 | 27 | 2.803738% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 963 | 963 | 43 | 43 | 4.47% | 4.47% |  |
| B | 963 | 963 | 40 | 40 | 4.15% | 4.15% |  |
| C | 963 | 963 | 35 | 35 | 3.63% | 3.63% |  |
| D | 963 | 963 | 25 | 25 | 2.60% | 2.60% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 237 | 211587 | 8453.69 | 115 | 113 | 25.0 |
| A | 13 | 6 | 5272 | 206.23 | 115 | 113 | 25.0 |
| A | 10 | 83 | 3722 | 144.27 | 115 | 113 | 25.0 |
| B | 5 | 172 | 173929 | 7176.9 | 113 | 110 | 24.2 |
| B | 0 | 213 | 11852 | 484.82 | 113 | 110 | 24.2 |
| B | 4 | 81 | 5045 | 203.76 | 113 | 110 | 24.2 |
| C | 0 | 10 | 83261 | 3018.61 | 110 | 110 | 27.5 |
| C | 15 | 214 | 48424 | 1753.93 | 110 | 110 | 27.5 |
| C | 14 | 254 | 36553 | 1322.98 | 110 | 110 | 27.5 |
| D | 1 | 52 | 153087 | 5207.88 | 112 | 108 | 29.4 |
| D | 8 | 195 | 86078 | 2926.68 | 112 | 108 | 29.4 |
| D | 2 | 249 | 53192 | 1807.14 | 112 | 108 | 29.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
