| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_086T01_9000004820_33786cztM0_level2.evt | modeM0/AS1A11_086T01_9000004820_33786cztM0_level2_quad_clean.evt |
| Size (bytes) | 724,956,480 | 71,349,120 |
| Size | 691.4 MB | 68.0 MB |
| Events in quadrant A | 4,778,462 | 472,204 |
| Events in quadrant B | 3,405,016 | 499,324 |
| Events in quadrant C | 2,975,053 | 509,634 |
| Events in quadrant D | 10,465,281 | 333,427 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 33 | 0 |
| B | 0 | 33 | 0 |
| C | 0 | 33 | 0 |
| D | 0 | 34 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 98 | 0 |
| B | 0 | 98 | 0 |
| C | 0 | 98 | 0 |
| D | 0 | 98 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17503 | 3 |
| B | 0 | 13417 | 2 |
| C | 0 | 11985 | 2 |
| D | 0 | 34450 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4924 | 771 | 15.658002% |
| B | 4924 | 173 | 3.513404% |
| C | 4924 | 51 | 1.035743% |
| D | 4924 | 3164 | 64.256702% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7046 | 4925 | 618 | 618 | 8.77% | 12.55% |  |
| B | 7046 | 4925 | 126 | 126 | 1.79% | 2.56% |  |
| C | 7046 | 4925 | 34 | 34 | 0.48% | 0.69% |  |
| D | 7046 | 4925 | 3300 | 3300 | 46.84% | 67.01% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 237 | 2350477 | 19878.93 | 595 | 585 | 118.2 |
| A | 15 | 169 | 105293 | 885.78 | 595 | 585 | 118.2 |
| A | 13 | 6 | 13313 | 107.67 | 595 | 585 | 118.2 |
| B | 5 | 172 | 584629 | 4992.96 | 633 | 620 | 117.0 |
| B | 5 | 207 | 72534 | 614.83 | 633 | 620 | 117.0 |
| B | 15 | 222 | 64016 | 542.0 | 633 | 620 | 117.0 |
| C | 15 | 214 | 215450 | 1503.91 | 631 | 639 | 142.8 |
| C | 3 | 233 | 131077 | 913.21 | 631 | 639 | 142.8 |
| C | 0 | 10 | 125290 | 872.69 | 631 | 639 | 142.8 |
| D | 12 | 235 | 6992355 | 65567.32 | 432 | 422 | 106.6 |
| D | 8 | 195 | 935827 | 8771.82 | 432 | 422 | 106.6 |
| D | 12 | 233 | 258898 | 2423.88 | 432 | 422 | 106.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
