| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_086T01_9000004820_33788cztM0_level2.evt | modeM0/AS1A11_086T01_9000004820_33788cztM0_level2_quad_clean.evt |
| Size (bytes) | 696,568,320 | 87,016,320 |
| Size | 664.3 MB | 83.0 MB |
| Events in quadrant A | 4,820,826 | 574,020 |
| Events in quadrant B | 3,935,299 | 601,762 |
| Events in quadrant C | 2,953,512 | 623,857 |
| Events in quadrant D | 9,030,149 | 464,832 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 40 | 0 |
| B | 0 | 40 | 0 |
| C | 0 | 40 | 0 |
| D | 0 | 40 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 108 | 0 |
| B | 0 | 108 | 0 |
| C | 0 | 108 | 0 |
| D | 0 | 108 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17859 | 3 |
| B | 0 | 15213 | 2 |
| C | 0 | 11861 | 2 |
| D | 0 | 30487 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5279 | 760 | 14.396666% |
| B | 5279 | 390 | 7.387763% |
| C | 5279 | 57 | 1.079750% |
| D | 5279 | 2077 | 39.344573% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9254 | 5281 | 600 | 600 | 6.48% | 11.36% |  |
| B | 9254 | 5281 | 299 | 299 | 3.23% | 5.66% |  |
| C | 9254 | 5281 | 46 | 46 | 0.50% | 0.87% |  |
| D | 9254 | 5281 | 2161 | 2161 | 23.35% | 40.92% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 237 | 2481501 | 21023.21 | 587 | 577 | 118.0 |
| A | 15 | 169 | 21232 | 175.03 | 587 | 577 | 118.0 |
| A | 13 | 6 | 15716 | 128.29 | 587 | 577 | 118.0 |
| B | 5 | 172 | 1192206 | 10127.05 | 608 | 592 | 117.7 |
| B | 4 | 171 | 87697 | 740.27 | 608 | 592 | 117.7 |
| B | 3 | 112 | 57389 | 482.69 | 608 | 592 | 117.7 |
| C | 15 | 214 | 230243 | 1621.79 | 612 | 617 | 141.6 |
| C | 3 | 233 | 168693 | 1187.08 | 612 | 617 | 141.6 |
| C | 0 | 10 | 123314 | 866.58 | 612 | 617 | 141.6 |
| D | 12 | 235 | 5380608 | 40408.66 | 508 | 497 | 133.1 |
| D | 8 | 195 | 893463 | 6706.84 | 508 | 497 | 133.1 |
| D | 2 | 250 | 333018 | 2497.48 | 508 | 497 | 133.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
