| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_086T01_9000004820_33795cztM0_level2.evt | modeM0/AS1A11_086T01_9000004820_33795cztM0_level2_quad_clean.evt |
| Size (bytes) | 692,242,560 | 60,932,160 |
| Size | 660.2 MB | 58.1 MB |
| Events in quadrant A | 4,006,274 | 383,515 |
| Events in quadrant B | 3,306,005 | 386,802 |
| Events in quadrant C | 3,229,642 | 394,030 |
| Events in quadrant D | 10,058,187 | 301,874 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 110 | 0 |
| B | 0 | 110 | 0 |
| C | 0 | 110 | 0 |
| D | 0 | 110 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15290 | 3 |
| B | 0 | 13078 | 2 |
| C | 0 | 12667 | 2 |
| D | 0 | 33616 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5397 | 480 | 8.893830% |
| B | 5397 | 192 | 3.557532% |
| C | 5397 | 36 | 0.667037% |
| D | 5397 | 2483 | 46.007041% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7100 | 5398 | 352 | 352 | 4.96% | 6.52% |  |
| B | 7100 | 5398 | 141 | 141 | 1.99% | 2.61% |  |
| C | 7100 | 5398 | 38 | 38 | 0.54% | 0.70% |  |
| D | 7100 | 5398 | 2511 | 2511 | 35.37% | 46.52% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 237 | 1551102 | 12340.59 | 626 | 614 | 125.6 |
| A | 13 | 6 | 15493 | 118.42 | 626 | 614 | 125.6 |
| A | 13 | 254 | 8913 | 66.05 | 626 | 614 | 125.6 |
| B | 5 | 172 | 570683 | 4684.82 | 633 | 616 | 121.7 |
| B | 0 | 213 | 42653 | 345.46 | 633 | 616 | 121.7 |
| B | 0 | 197 | 39214 | 317.2 | 633 | 616 | 121.7 |
| C | 15 | 214 | 246769 | 1677.67 | 629 | 632 | 146.7 |
| C | 14 | 254 | 152184 | 1032.98 | 629 | 632 | 146.7 |
| C | 4 | 254 | 126487 | 857.83 | 629 | 632 | 146.7 |
| D | 12 | 235 | 6456446 | 51255.76 | 513 | 500 | 126.0 |
| D | 8 | 195 | 1093528 | 8677.89 | 513 | 500 | 126.0 |
| D | 2 | 250 | 199611 | 1580.8 | 513 | 500 | 126.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
