| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_106T03_9000004826_33817cztM0_level2.evt | modeM0/AS1A11_106T03_9000004826_33817cztM0_level2_quad_clean.evt |
| Size (bytes) | 453,003,840 | 93,453,120 |
| Size | 432.0 MB | 89.1 MB |
| Events in quadrant A | 2,418,242 | 626,141 |
| Events in quadrant B | 3,651,421 | 616,393 |
| Events in quadrant C | 2,922,463 | 629,346 |
| Events in quadrant D | 4,376,754 | 596,558 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 36 | 0 |
| B | 0 | 36 | 0 |
| C | 0 | 36 | 0 |
| D | 0 | 37 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 106 | 0 |
| B | 0 | 106 | 0 |
| C | 0 | 106 | 0 |
| D | 0 | 106 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10572 | 3 |
| B | 0 | 14266 | 2 |
| C | 0 | 11750 | 2 |
| D | 0 | 16680 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5160 | 30 | 0.581395% |
| B | 5160 | 312 | 6.046512% |
| C | 5160 | 105 | 2.034884% |
| D | 5160 | 76 | 1.472868% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7043 | 5161 | 16 | 16 | 0.23% | 0.31% |  |
| B | 7043 | 5161 | 239 | 239 | 3.39% | 4.63% |  |
| C | 7043 | 5161 | 81 | 81 | 1.15% | 1.57% |  |
| D | 7043 | 5161 | 77 | 77 | 1.09% | 1.49% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 65272 | 529.6 | 600 | 588 | 122.1 |
| A | 13 | 6 | 24326 | 194.35 | 600 | 588 | 122.1 |
| A | 10 | 83 | 10770 | 83.36 | 600 | 588 | 122.1 |
| B | 5 | 172 | 1064260 | 9591.08 | 588 | 575 | 110.9 |
| B | 4 | 251 | 123288 | 1106.48 | 588 | 575 | 110.9 |
| B | 0 | 213 | 36627 | 325.08 | 588 | 575 | 110.9 |
| C | 0 | 10 | 279548 | 2061.78 | 587 | 593 | 135.3 |
| C | 15 | 214 | 222624 | 1641.05 | 587 | 593 | 135.3 |
| C | 14 | 254 | 48550 | 354.45 | 587 | 593 | 135.3 |
| D | 8 | 195 | 1202397 | 7911.5 | 582 | 569 | 151.9 |
| D | 12 | 235 | 298001 | 1957.96 | 582 | 569 | 151.9 |
| D | 2 | 250 | 157706 | 1034.42 | 582 | 569 | 151.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
