| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_089T01_9000004832_33855cztM0_level2.evt | modeM0/AS1T04_089T01_9000004832_33855cztM0_level2_quad_clean.evt |
| Size (bytes) | 118,797,120 | 27,538,560 |
| Size | 113.3 MB | 26.3 MB |
| Events in quadrant A | 752,207 | 187,183 |
| Events in quadrant B | 911,070 | 184,838 |
| Events in quadrant C | 848,857 | 183,280 |
| Events in quadrant D | 989,291 | 175,363 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3005 | 26 |
| B | 0 | 3596 | 51 |
| C | 0 | 3338 | 19 |
| D | 0 | 3899 | 26 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 30 | 0 |
| B | 0 | 30 | 0 |
| C | 0 | 30 | 0 |
| D | 0 | 30 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 1376 | 2 | 0.145349% |
| B | 1376 | 46 | 3.343023% |
| C | 1379 | 29 | 2.102973% |
| D | 1378 | 22 | 1.596517% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3210 | 1381 | 0 | 0 | 0.00% | 0.00% |  |
| B | 3210 | 1379 | 27 | 27 | 0.84% | 1.96% |  |
| C | 3210 | 1383 | 23 | 23 | 0.72% | 1.66% |  |
| D | 3210 | 1381 | 18 | 18 | 0.56% | 1.30% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 39084 | 1025.49 | 182 | 179 | 37.9 |
| A | 10 | 83 | 4901 | 124.47 | 182 | 179 | 37.9 |
| A | 13 | 6 | 2949 | 73.01 | 182 | 179 | 37.9 |
| B | 5 | 172 | 144859 | 4048.43 | 177 | 173 | 35.7 |
| B | 0 | 190 | 38363 | 1068.59 | 177 | 173 | 35.7 |
| B | 4 | 232 | 28711 | 798.52 | 177 | 173 | 35.7 |
| C | 0 | 10 | 74878 | 1814.31 | 173 | 175 | 41.2 |
| C | 15 | 214 | 63004 | 1525.93 | 173 | 175 | 41.2 |
| C | 9 | 54 | 18177 | 437.21 | 173 | 175 | 41.2 |
| D | 8 | 195 | 126247 | 2917.87 | 174 | 169 | 43.2 |
| D | 13 | 249 | 107801 | 2490.96 | 174 | 169 | 43.2 |
| D | 2 | 250 | 35338 | 813.93 | 174 | 169 | 43.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
