| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_003T04_9000004866_34019cztM0_level2.evt | modeM0/AS1A06_003T04_9000004866_34019cztM0_level2_quad_clean.evt |
| Size (bytes) | 84,346,560 | 16,058,880 |
| Size | 80.4 MB | 15.3 MB |
| Events in quadrant A | 435,544 | 109,117 |
| Events in quadrant B | 818,015 | 98,844 |
| Events in quadrant C | 567,568 | 105,897 |
| Events in quadrant D | 671,258 | 103,872 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1767 | 2 |
| B | 0 | 2969 | 1 |
| C | 0 | 2166 | 1 |
| D | 0 | 2656 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 865 | 1 | 0.115607% |
| B | 865 | 169 | 19.537572% |
| C | 865 | 55 | 6.358382% |
| D | 865 | 8 | 0.924855% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 2898 | 866 | 0 | 0 | 0.00% | 0.00% |  |
| B | 2898 | 866 | 130 | 130 | 4.49% | 15.01% |  |
| C | 2898 | 866 | 25 | 25 | 0.86% | 2.89% |  |
| D | 2898 | 866 | 7 | 7 | 0.24% | 0.81% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 7393 | 303.98 | 109 | 106 | 24.0 |
| A | 15 | 169 | 3262 | 131.65 | 109 | 106 | 24.0 |
| A | 13 | 6 | 2065 | 81.72 | 109 | 106 | 24.0 |
| B | 5 | 172 | 400401 | 18822.1 | 97 | 95 | 21.3 |
| B | 4 | 232 | 12164 | 567.48 | 97 | 95 | 21.3 |
| B | 0 | 189 | 11843 | 552.38 | 97 | 95 | 21.3 |
| C | 0 | 10 | 111809 | 4406.9 | 100 | 101 | 25.3 |
| C | 15 | 214 | 43666 | 1718.64 | 100 | 101 | 25.3 |
| C | 3 | 233 | 11889 | 465.04 | 100 | 101 | 25.3 |
| D | 8 | 195 | 212232 | 7809.18 | 105 | 102 | 27.2 |
| D | 2 | 250 | 23017 | 843.57 | 105 | 102 | 27.2 |
| D | 13 | 249 | 8388 | 305.03 | 105 | 102 | 27.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
