| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_001T04_9000004868_34079cztM0_level2.evt | modeM0/AS1C07_001T04_9000004868_34079cztM0_level2_quad_clean.evt |
| Size (bytes) | 576,907,200 | 85,066,560 |
| Size | 550.2 MB | 81.1 MB |
| Events in quadrant A | 2,720,828 | 569,831 |
| Events in quadrant B | 6,114,129 | 538,765 |
| Events in quadrant C | 3,472,274 | 547,013 |
| Events in quadrant D | 4,777,755 | 520,475 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 21 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 118 | 0 |
| B | 0 | 118 | 0 |
| C | 0 | 118 | 0 |
| D | 0 | 118 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11762 | 3 |
| B | 0 | 22143 | 2 |
| C | 0 | 13686 | 2 |
| D | 0 | 18001 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5710 | 37 | 0.647986% |
| B | 5710 | 745 | 13.047285% |
| C | 5710 | 140 | 2.451839% |
| D | 5710 | 162 | 2.837128% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7112 | 5709 | 25 | 25 | 0.35% | 0.44% |  |
| B | 7112 | 5709 | 535 | 535 | 7.52% | 9.37% |  |
| C | 7112 | 5709 | 131 | 131 | 1.84% | 2.29% |  |
| D | 7112 | 5710 | 152 | 152 | 2.14% | 2.66% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 157703 | 1195.79 | 654 | 642 | 131.3 |
| A | 10 | 83 | 19127 | 140.74 | 654 | 642 | 131.3 |
| A | 13 | 6 | 15551 | 113.51 | 654 | 642 | 131.3 |
| B | 5 | 31 | 1709754 | 14142.37 | 624 | 608 | 120.9 |
| B | 5 | 172 | 717157 | 5929.1 | 624 | 608 | 120.9 |
| B | 5 | 15 | 560644 | 4634.03 | 624 | 608 | 120.9 |
| C | 0 | 10 | 488594 | 3387.82 | 625 | 630 | 144.0 |
| C | 15 | 214 | 246329 | 1705.83 | 625 | 630 | 144.0 |
| C | 0 | 207 | 131545 | 908.91 | 625 | 630 | 144.0 |
| D | 8 | 195 | 1387181 | 9005.23 | 627 | 608 | 154.0 |
| D | 2 | 250 | 294632 | 1909.57 | 627 | 608 | 154.0 |
| D | 1 | 52 | 245271 | 1588.99 | 627 | 608 | 154.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
