| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_093T01_9000004872_34107cztM0_level2.evt | modeM0/AS1T04_093T01_9000004872_34107cztM0_level2_quad_clean.evt |
| Size (bytes) | 530,997,120 | 54,138,240 |
| Size | 506.4 MB | 51.6 MB |
| Events in quadrant A | 2,571,058 | 326,179 |
| Events in quadrant B | 4,813,593 | 311,179 |
| Events in quadrant C | 4,025,283 | 312,882 |
| Events in quadrant D | 4,297,778 | 302,729 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11082 | 3 |
| B | 0 | 17887 | 9 |
| C | 0 | 15287 | 2 |
| D | 0 | 16456 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 114 | 0 |
| B | 0 | 114 | 0 |
| C | 0 | 114 | 0 |
| D | 0 | 114 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31 | 0 |
| B | 0 | 31 | 0 |
| C | 0 | 31 | 0 |
| D | 0 | 31 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5507 | 6 | 0.108952% |
| B | 5506 | 722 | 13.112968% |
| C | 5507 | 262 | 4.757581% |
| D | 5507 | 225 | 4.085709% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7210 | 5508 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7210 | 5508 | 505 | 505 | 7.00% | 9.17% |  |
| C | 7210 | 5508 | 217 | 217 | 3.01% | 3.94% |  |
| D | 7210 | 5508 | 150 | 150 | 2.08% | 2.72% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 19786 | 145.8 | 656 | 642 | 131.3 |
| A | 13 | 6 | 16075 | 117.54 | 656 | 642 | 131.3 |
| A | 13 | 254 | 10579 | 75.68 | 656 | 642 | 131.3 |
| B | 5 | 172 | 2147891 | 18141.43 | 618 | 604 | 118.4 |
| B | 0 | 199 | 64253 | 537.74 | 618 | 604 | 118.4 |
| B | 0 | 189 | 63237 | 529.16 | 618 | 604 | 118.4 |
| C | 0 | 10 | 601154 | 4151.17 | 623 | 628 | 144.7 |
| C | 0 | 239 | 502017 | 3465.88 | 623 | 628 | 144.7 |
| C | 15 | 214 | 238356 | 1643.31 | 623 | 628 | 144.7 |
| D | 8 | 195 | 906548 | 5954.9 | 623 | 606 | 152.1 |
| D | 13 | 249 | 441994 | 2901.31 | 623 | 606 | 152.1 |
| D | 7 | 223 | 166047 | 1087.47 | 623 | 606 | 152.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
