| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_093T01_9000004872_34115cztM0_level2.evt | modeM0/AS1T04_093T01_9000004872_34115cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,091,548,800 | 160,032,960 |
| Size | 1.0 GB | 152.6 MB |
| Events in quadrant A | 5,614,968 | 1,029,427 |
| Events in quadrant B | 7,270,935 | 1,033,029 |
| Events in quadrant C | 9,146,104 | 970,258 |
| Events in quadrant D | 10,202,198 | 969,655 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24768 | 1 |
| B | 0 | 29433 | 1 |
| C | 0 | 34541 | 1 |
| D | 0 | 38524 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 246 | 0 |
| B | 0 | 246 | 0 |
| C | 0 | 246 | 0 |
| D | 0 | 246 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27 | 0 |
| B | 0 | 27 | 0 |
| C | 0 | 27 | 0 |
| D | 0 | 27 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 12217 | 21 | 0.171892% |
| B | 12217 | 312 | 2.553818% |
| C | 12217 | 864 | 7.072113% |
| D | 12217 | 500 | 4.092658% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 14843 | 12219 | 6 | 6 | 0.04% | 0.05% |  |
| B | 14843 | 12219 | 184 | 184 | 1.24% | 1.51% |  |
| C | 14843 | 12219 | 757 | 757 | 5.10% | 6.20% |  |
| D | 14843 | 12218 | 376 | 376 | 2.53% | 3.08% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 60420 | 206.74 | 1421 | 1390 | 285.5 |
| A | 13 | 6 | 32784 | 109.95 | 1421 | 1390 | 285.5 |
| A | 10 | 83 | 27991 | 93.17 | 1421 | 1390 | 285.5 |
| B | 5 | 172 | 948947 | 3521.04 | 1404 | 1369 | 269.1 |
| B | 0 | 189 | 229313 | 847.0 | 1404 | 1369 | 269.1 |
| B | 5 | 31 | 143053 | 526.47 | 1404 | 1369 | 269.1 |
| C | 14 | 254 | 1893874 | 6110.85 | 1339 | 1351 | 309.7 |
| C | 0 | 10 | 1426131 | 4600.53 | 1339 | 1351 | 309.7 |
| C | 15 | 214 | 510144 | 1642.86 | 1339 | 1351 | 309.7 |
| D | 8 | 195 | 2690578 | 7379.35 | 1348 | 1321 | 364.4 |
| D | 13 | 249 | 585747 | 1603.67 | 1348 | 1321 | 364.4 |
| D | 7 | 223 | 345195 | 943.59 | 1348 | 1321 | 364.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
