| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_059T05_9000004876_34141cztM0_level2.evt | modeM0/AS1A11_059T05_9000004876_34141cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,703,701,440 | 203,938,560 |
| Size | 1.6 GB | 194.5 MB |
| Events in quadrant A | 7,126,347 | 1,352,461 |
| Events in quadrant B | 22,711,717 | 1,144,444 |
| Events in quadrant C | 9,490,948 | 1,328,608 |
| Events in quadrant D | 11,212,535 | 1,267,421 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 50 | 0 |
| B | 0 | 50 | 0 |
| C | 0 | 50 | 0 |
| D | 0 | 51 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31674 | 4 |
| B | 0 | 78021 | 3 |
| C | 0 | 38017 | 3 |
| D | 0 | 43793 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 320 | 0 |
| B | 0 | 320 | 0 |
| C | 0 | 320 | 0 |
| D | 0 | 320 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 15683 | 16 | 0.102021% |
| B | 15683 | 5965 | 38.034815% |
| C | 15683 | 326 | 2.078684% |
| D | 15683 | 191 | 1.217879% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 19862 | 15686 | 0 | 0 | 0.00% | 0.00% |  |
| B | 19862 | 15686 | 5084 | 5084 | 25.60% | 32.41% |  |
| C | 19862 | 15686 | 252 | 252 | 1.27% | 1.61% |  |
| D | 19862 | 15686 | 190 | 190 | 0.96% | 1.21% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 44143 | 115.76 | 1824 | 1786 | 365.9 |
| A | 13 | 6 | 26905 | 68.65 | 1824 | 1786 | 365.9 |
| A | 13 | 254 | 26612 | 67.85 | 1824 | 1786 | 365.9 |
| B | 5 | 31 | 9899406 | 32246.15 | 1607 | 1563 | 306.9 |
| B | 5 | 15 | 5112438 | 16650.7 | 1607 | 1563 | 306.9 |
| B | 5 | 14 | 789112 | 2565.75 | 1607 | 1563 | 306.9 |
| C | 0 | 10 | 1245536 | 3061.79 | 1753 | 1768 | 406.2 |
| C | 15 | 214 | 677164 | 1662.63 | 1753 | 1768 | 406.2 |
| C | 14 | 254 | 581938 | 1428.21 | 1753 | 1768 | 406.2 |
| D | 8 | 195 | 2965518 | 6826.72 | 1763 | 1719 | 434.1 |
| D | 7 | 223 | 404297 | 927.29 | 1763 | 1719 | 434.1 |
| D | 13 | 249 | 282378 | 646.46 | 1763 | 1719 | 434.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
