| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_047T15_9000004882_34180cztM0_level2.evt | modeM0/AS1A11_047T15_9000004882_34180cztM0_level2_quad_clean.evt |
| Size (bytes) | 607,147,200 | 69,845,760 |
| Size | 579.0 MB | 66.6 MB |
| Events in quadrant A | 2,646,482 | 444,275 |
| Events in quadrant B | 7,875,040 | 429,947 |
| Events in quadrant C | 3,621,320 | 427,706 |
| Events in quadrant D | 3,855,972 | 411,720 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 118 | 0 |
| B | 0 | 118 | 0 |
| C | 0 | 118 | 0 |
| D | 0 | 118 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 18 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11550 | 3 |
| B | 0 | 27410 | 2 |
| C | 0 | 14344 | 2 |
| D | 0 | 15383 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5731 | 7 | 0.122143% |
| B | 5731 | 2150 | 37.515268% |
| C | 5731 | 160 | 2.791834% |
| D | 5731 | 35 | 0.610714% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7225 | 5732 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7225 | 5732 | 1725 | 1725 | 23.88% | 30.09% |  |
| C | 7225 | 5732 | 141 | 141 | 1.95% | 2.46% |  |
| D | 7225 | 5732 | 23 | 23 | 0.32% | 0.40% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 21888 | 156.55 | 671 | 658 | 135.6 |
| A | 15 | 223 | 19325 | 137.65 | 671 | 658 | 135.6 |
| A | 13 | 6 | 11338 | 78.75 | 671 | 658 | 135.6 |
| B | 5 | 31 | 2817405 | 24962.52 | 582 | 565 | 112.8 |
| B | 5 | 15 | 1837273 | 16276.7 | 582 | 565 | 112.8 |
| B | 5 | 14 | 394360 | 3489.76 | 582 | 565 | 112.8 |
| C | 0 | 10 | 529528 | 3553.77 | 640 | 646 | 148.8 |
| C | 15 | 214 | 262914 | 1762.28 | 640 | 646 | 148.8 |
| C | 0 | 239 | 203637 | 1363.98 | 640 | 646 | 148.8 |
| D | 8 | 195 | 1091061 | 6842.11 | 646 | 627 | 159.4 |
| D | 10 | 118 | 70781 | 440.19 | 646 | 627 | 159.4 |
| D | 7 | 223 | 41361 | 255.59 | 646 | 627 | 159.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
