| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_047T15_9000004882_34188cztM0_level2.evt | modeM0/AS1A11_047T15_9000004882_34188cztM0_level2_quad_clean.evt |
| Size (bytes) | 564,863,040 | 65,865,600 |
| Size | 538.7 MB | 62.8 MB |
| Events in quadrant A | 3,036,416 | 416,941 |
| Events in quadrant B | 5,510,207 | 406,252 |
| Events in quadrant C | 3,703,951 | 416,377 |
| Events in quadrant D | 4,501,327 | 387,288 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 108 | 0 |
| B | 0 | 108 | 0 |
| C | 0 | 108 | 0 |
| D | 0 | 108 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 19 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12418 | 3 |
| B | 0 | 19995 | 2 |
| C | 0 | 14230 | 2 |
| D | 0 | 17090 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5242 | 250 | 4.769172% |
| B | 5242 | 922 | 17.588707% |
| C | 5242 | 352 | 6.714994% |
| D | 5242 | 134 | 2.556276% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7066 | 5243 | 212 | 212 | 3.00% | 4.04% |  |
| B | 7066 | 5243 | 688 | 688 | 9.74% | 13.12% |  |
| C | 7066 | 5243 | 234 | 234 | 3.31% | 4.46% |  |
| D | 7066 | 5243 | 125 | 125 | 1.77% | 2.38% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 525447 | 4059.2 | 641 | 630 | 129.3 |
| A | 10 | 83 | 23411 | 176.2 | 641 | 630 | 129.3 |
| A | 13 | 6 | 9904 | 71.73 | 641 | 630 | 129.3 |
| B | 5 | 172 | 1460760 | 12704.48 | 601 | 585 | 114.9 |
| B | 5 | 31 | 1077041 | 9365.87 | 601 | 585 | 114.9 |
| B | 5 | 15 | 432661 | 3759.34 | 601 | 585 | 114.9 |
| C | 14 | 254 | 641172 | 4466.94 | 621 | 626 | 143.4 |
| C | 0 | 10 | 361996 | 2520.07 | 621 | 626 | 143.4 |
| C | 15 | 214 | 234536 | 1631.2 | 621 | 626 | 143.4 |
| D | 8 | 195 | 1089527 | 6363.93 | 624 | 612 | 171.1 |
| D | 7 | 80 | 262929 | 1533.05 | 624 | 612 | 171.1 |
| D | 7 | 223 | 255257 | 1488.22 | 624 | 612 | 171.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
