| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_047T15_9000004882_34195cztM0_level2.evt | modeM0/AS1A11_047T15_9000004882_34195cztM0_level2_quad_clean.evt |
| Size (bytes) | 512,337,600 | 68,961,600 |
| Size | 488.6 MB | 65.8 MB |
| Events in quadrant A | 2,609,162 | 435,223 |
| Events in quadrant B | 4,413,037 | 430,986 |
| Events in quadrant C | 3,423,817 | 422,883 |
| Events in quadrant D | 4,685,357 | 401,910 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11420 | 2 |
| B | 0 | 17019 | 1 |
| C | 0 | 13585 | 1 |
| D | 0 | 17896 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5675 | 3 | 0.052863% |
| B | 5675 | 433 | 7.629956% |
| C | 5675 | 130 | 2.290749% |
| D | 5675 | 223 | 3.929515% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7048 | 5676 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7048 | 5676 | 227 | 227 | 3.22% | 4.00% |  |
| C | 7048 | 5676 | 109 | 109 | 1.55% | 1.92% |  |
| D | 7048 | 5676 | 159 | 159 | 2.26% | 2.80% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 15615 | 111.29 | 665 | 654 | 134.4 |
| A | 13 | 6 | 14598 | 103.73 | 665 | 654 | 134.4 |
| A | 13 | 254 | 9656 | 66.96 | 665 | 654 | 134.4 |
| B | 5 | 31 | 705764 | 5716.94 | 642 | 627 | 123.3 |
| B | 5 | 172 | 597796 | 4841.58 | 642 | 627 | 123.3 |
| B | 5 | 15 | 393070 | 3181.75 | 642 | 627 | 123.3 |
| C | 0 | 239 | 404364 | 2748.6 | 634 | 638 | 146.9 |
| C | 15 | 214 | 258870 | 1758.06 | 634 | 638 | 146.9 |
| C | 0 | 10 | 243690 | 1654.72 | 634 | 638 | 146.9 |
| D | 8 | 195 | 1156651 | 7422.7 | 632 | 614 | 155.7 |
| D | 13 | 249 | 178899 | 1144.74 | 632 | 614 | 155.7 |
| D | 1 | 52 | 175924 | 1125.63 | 632 | 614 | 155.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
