| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_086T01_9000004884_34208cztM0_level2.evt | modeM0/AS1T04_086T01_9000004884_34208cztM0_level2_quad_clean.evt |
| Size (bytes) | 724,452,480 | 70,341,120 |
| Size | 690.9 MB | 67.1 MB |
| Events in quadrant A | 2,534,935 | 477,316 |
| Events in quadrant B | 8,982,240 | 370,495 |
| Events in quadrant C | 2,923,705 | 490,543 |
| Events in quadrant D | 7,146,674 | 423,968 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 106 | 0 |
| B | 0 | 106 | 0 |
| C | 0 | 106 | 0 |
| D | 0 | 106 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 21 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10881 | 3 |
| B | 0 | 30281 | 2 |
| C | 0 | 11674 | 2 |
| D | 0 | 24849 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5232 | 20 | 0.382263% |
| B | 5232 | 2403 | 45.928899% |
| C | 5232 | 99 | 1.892202% |
| D | 5232 | 956 | 18.272171% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7054 | 5233 | 17 | 17 | 0.24% | 0.32% |  |
| B | 7054 | 5233 | 2055 | 2055 | 29.13% | 39.27% |  |
| C | 7054 | 5233 | 68 | 68 | 0.96% | 1.30% |  |
| D | 7054 | 5233 | 901 | 901 | 12.77% | 17.22% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 81169 | 650.2 | 614 | 604 | 123.9 |
| A | 9 | 143 | 31647 | 250.53 | 614 | 604 | 123.9 |
| A | 10 | 83 | 22789 | 179.04 | 614 | 604 | 123.9 |
| B | 5 | 31 | 4532352 | 46082.56 | 518 | 506 | 98.3 |
| B | 5 | 15 | 1822469 | 18526.82 | 518 | 506 | 98.3 |
| B | 5 | 172 | 285091 | 2893.83 | 518 | 506 | 98.3 |
| C | 0 | 10 | 259868 | 1885.83 | 598 | 603 | 137.5 |
| C | 15 | 214 | 243298 | 1765.31 | 598 | 603 | 137.5 |
| C | 4 | 254 | 51686 | 371.57 | 598 | 603 | 137.5 |
| D | 12 | 217 | 2266738 | 16376.18 | 565 | 549 | 138.4 |
| D | 8 | 195 | 1216122 | 8784.1 | 565 | 549 | 138.4 |
| D | 2 | 250 | 957072 | 6912.13 | 565 | 549 | 138.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
