| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_086T01_9000004890_34283cztM0_level2.evt | modeM0/AS1T04_086T01_9000004890_34283cztM0_level2_quad_clean.evt |
| Size (bytes) | 565,338,240 | 89,271,360 |
| Size | 539.1 MB | 85.1 MB |
| Events in quadrant A | 2,820,528 | 577,631 |
| Events in quadrant B | 3,518,616 | 586,661 |
| Events in quadrant C | 3,128,637 | 596,751 |
| Events in quadrant D | 7,237,347 | 512,832 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12445 | 3 |
| B | 0 | 14336 | 2 |
| C | 0 | 12929 | 2 |
| D | 0 | 25662 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27 | 0 |
| B | 0 | 27 | 0 |
| C | 0 | 27 | 0 |
| D | 0 | 27 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6151 | 7 | 0.113803% |
| B | 6151 | 98 | 1.593237% |
| C | 6151 | 7 | 0.113803% |
| D | 6151 | 910 | 14.794342% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8805 | 6153 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8805 | 6153 | 55 | 55 | 0.62% | 0.89% |  |
| C | 8805 | 6153 | 5 | 5 | 0.06% | 0.08% |  |
| D | 8805 | 6153 | 838 | 838 | 9.52% | 13.62% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 27122 | 183.65 | 711 | 696 | 143.9 |
| A | 9 | 143 | 22895 | 154.27 | 711 | 696 | 143.9 |
| A | 13 | 254 | 11148 | 72.64 | 711 | 696 | 143.9 |
| B | 5 | 172 | 253444 | 1852.95 | 705 | 686 | 136.4 |
| B | 4 | 251 | 206029 | 1505.35 | 705 | 686 | 136.4 |
| B | 0 | 229 | 177806 | 1298.45 | 705 | 686 | 136.4 |
| C | 15 | 214 | 267230 | 1660.81 | 698 | 706 | 160.5 |
| C | 4 | 254 | 75064 | 463.35 | 698 | 706 | 160.5 |
| C | 0 | 10 | 27160 | 164.85 | 698 | 706 | 160.5 |
| D | 7 | 80 | 1703509 | 10567.0 | 659 | 640 | 161.1 |
| D | 8 | 195 | 975221 | 6047.67 | 659 | 640 | 161.1 |
| D | 12 | 235 | 655835 | 4065.75 | 659 | 640 | 161.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
