| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_019T01_9000004906_34368cztM0_level2.evt | modeM0/AS1A05_019T01_9000004906_34368cztM0_level2_quad_clean.evt |
| Size (bytes) | 577,771,200 | 55,903,680 |
| Size | 551.0 MB | 53.3 MB |
| Events in quadrant A | 2,554,732 | 351,800 |
| Events in quadrant B | 3,707,936 | 348,902 |
| Events in quadrant C | 5,165,049 | 297,534 |
| Events in quadrant D | 5,695,834 | 306,611 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11281 | 3 |
| B | 0 | 14658 | 2 |
| C | 0 | 18891 | 2 |
| D | 0 | 20865 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 34 | 0 |
| B | 0 | 34 | 0 |
| C | 0 | 34 | 0 |
| D | 0 | 34 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5526 | 7 | 0.126674% |
| B | 5526 | 243 | 4.397394% |
| C | 5526 | 813 | 14.712269% |
| D | 5526 | 693 | 12.540717% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8992 | 5528 | 4 | 4 | 0.04% | 0.07% |  |
| B | 8992 | 5528 | 159 | 159 | 1.77% | 2.88% |  |
| C | 8992 | 5528 | 712 | 712 | 7.92% | 12.88% |  |
| D | 8991 | 5526 | 657 | 657 | 7.31% | 11.89% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 143 | 34175 | 259.51 | 640 | 626 | 129.3 |
| A | 10 | 83 | 31784 | 241.02 | 640 | 626 | 129.3 |
| A | 13 | 254 | 9110 | 65.63 | 640 | 626 | 129.3 |
| B | 5 | 172 | 787097 | 6376.8 | 628 | 612 | 123.3 |
| B | 0 | 229 | 183816 | 1485.41 | 628 | 612 | 123.3 |
| B | 0 | 190 | 81957 | 659.54 | 628 | 612 | 123.3 |
| C | 4 | 254 | 2552912 | 18614.53 | 587 | 593 | 137.1 |
| C | 15 | 214 | 220716 | 1605.4 | 587 | 593 | 137.1 |
| C | 0 | 10 | 70165 | 507.4 | 587 | 593 | 137.1 |
| D | 7 | 223 | 1363370 | 9443.43 | 588 | 570 | 144.3 |
| D | 8 | 195 | 882667 | 6112.43 | 588 | 570 | 144.3 |
| D | 1 | 52 | 653125 | 4521.83 | 588 | 570 | 144.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
