| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_085T01_9000004910_34378cztM0_level2.evt | modeM0/AS1A05_085T01_9000004910_34378cztM0_level2_quad_clean.evt |
| Size (bytes) | 577,532,160 | 84,257,280 |
| Size | 550.8 MB | 80.4 MB |
| Events in quadrant A | 2,549,715 | 598,547 |
| Events in quadrant B | 3,536,886 | 587,739 |
| Events in quadrant C | 4,690,666 | 566,880 |
| Events in quadrant D | 6,372,673 | 444,757 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 102 | 0 |
| B | 0 | 102 | 0 |
| C | 0 | 102 | 0 |
| D | 0 | 102 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 21 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10604 | 2 |
| B | 0 | 13754 | 1 |
| C | 0 | 17488 | 1 |
| D | 0 | 22377 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5038 | 7 | 0.138944% |
| B | 5038 | 258 | 5.121080% |
| C | 5038 | 431 | 8.554982% |
| D | 5038 | 1253 | 24.870981% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7072 | 5039 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7071 | 5038 | 192 | 192 | 2.72% | 3.81% |  |
| C | 7072 | 5039 | 385 | 385 | 5.44% | 7.64% |  |
| D | 7072 | 5039 | 1195 | 1195 | 16.90% | 23.72% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 6 | 28693 | 222.04 | 634 | 626 | 126.4 |
| A | 10 | 83 | 21168 | 162.51 | 634 | 626 | 126.4 |
| A | 7 | 16 | 20989 | 161.09 | 634 | 626 | 126.4 |
| B | 5 | 172 | 724488 | 6193.9 | 619 | 607 | 116.9 |
| B | 4 | 251 | 122374 | 1041.9 | 619 | 607 | 116.9 |
| B | 15 | 85 | 62905 | 533.05 | 619 | 607 | 116.9 |
| C | 4 | 254 | 2067084 | 15376.74 | 583 | 588 | 134.4 |
| C | 15 | 214 | 203043 | 1506.46 | 583 | 588 | 134.4 |
| C | 0 | 10 | 60665 | 447.03 | 583 | 588 | 134.4 |
| D | 7 | 223 | 2045812 | 16056.61 | 521 | 506 | 127.4 |
| D | 8 | 195 | 646509 | 5071.43 | 521 | 506 | 127.4 |
| D | 2 | 249 | 542801 | 4257.27 | 521 | 506 | 127.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
