| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_058T05_9000004918_34446cztM0_level2.evt | modeM0/AS1A10_058T05_9000004918_34446cztM0_level2_quad_clean.evt |
| Size (bytes) | 661,717,440 | 87,226,560 |
| Size | 631.1 MB | 83.2 MB |
| Events in quadrant A | 3,389,310 | 548,467 |
| Events in quadrant B | 4,820,296 | 548,187 |
| Events in quadrant C | 3,974,686 | 545,871 |
| Events in quadrant D | 7,374,751 | 503,018 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 32 | 0 |
| B | 0 | 32 | 0 |
| C | 0 | 32 | 0 |
| D | 0 | 32 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14448 | 3 |
| B | 0 | 18855 | 2 |
| C | 0 | 15858 | 2 |
| D | 0 | 27074 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 146 | 0 |
| B | 0 | 146 | 0 |
| C | 0 | 146 | 0 |
| D | 0 | 146 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7123 | 6 | 0.084234% |
| B | 7123 | 462 | 6.486031% |
| C | 7123 | 21 | 0.294820% |
| D | 7123 | 358 | 5.025972% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 10259 | 7125 | 0 | 0 | 0.00% | 0.00% |  |
| B | 10259 | 7125 | 305 | 305 | 2.97% | 4.28% |  |
| C | 10259 | 7125 | 8 | 8 | 0.08% | 0.11% |  |
| D | 10259 | 7125 | 298 | 298 | 2.90% | 4.18% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 38527 | 217.75 | 858 | 839 | 173.1 |
| A | 13 | 6 | 18262 | 100.66 | 858 | 839 | 173.1 |
| A | 10 | 255 | 13573 | 73.57 | 858 | 839 | 173.1 |
| B | 5 | 172 | 1180314 | 7409.25 | 828 | 808 | 159.2 |
| B | 0 | 229 | 137804 | 860.56 | 828 | 808 | 159.2 |
| B | 0 | 190 | 109115 | 680.35 | 828 | 808 | 159.2 |
| C | 4 | 254 | 338494 | 1751.72 | 834 | 839 | 192.8 |
| C | 15 | 214 | 300131 | 1552.7 | 834 | 839 | 192.8 |
| C | 3 | 233 | 35769 | 181.21 | 834 | 839 | 192.8 |
| D | 8 | 195 | 2571576 | 12711.41 | 819 | 795 | 202.2 |
| D | 7 | 80 | 537291 | 2652.74 | 819 | 795 | 202.2 |
| D | 12 | 235 | 487547 | 2406.78 | 819 | 795 | 202.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
