| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_156T01_9000004928_34495cztM0_level2.evt | modeM0/AS1A05_156T01_9000004928_34495cztM0_level2_quad_clean.evt |
| Size (bytes) | 496,946,880 | 57,847,680 |
| Size | 473.9 MB | 55.2 MB |
| Events in quadrant A | 2,845,247 | 355,719 |
| Events in quadrant B | 4,046,088 | 353,257 |
| Events in quadrant C | 3,016,125 | 352,393 |
| Events in quadrant D | 4,794,304 | 329,678 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 106 | 0 |
| B | 0 | 106 | 0 |
| C | 0 | 106 | 0 |
| D | 0 | 106 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11581 | 3 |
| B | 0 | 15297 | 2 |
| C | 0 | 12065 | 2 |
| D | 0 | 17889 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 32 | 0 |
| B | 0 | 32 | 0 |
| C | 0 | 32 | 0 |
| D | 0 | 33 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5139 | 10 | 0.194590% |
| B | 5139 | 483 | 9.398716% |
| C | 5139 | 40 | 0.778362% |
| D | 5139 | 313 | 6.090679% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7262 | 5140 | 3 | 3 | 0.04% | 0.06% |  |
| B | 7262 | 5140 | 335 | 335 | 4.61% | 6.52% |  |
| C | 7262 | 5140 | 30 | 30 | 0.41% | 0.58% |  |
| D | 7262 | 5140 | 281 | 281 | 3.87% | 5.47% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 78531 | 571.7 | 683 | 672 | 136.2 |
| A | 9 | 143 | 55384 | 401.73 | 683 | 672 | 136.2 |
| A | 10 | 83 | 38914 | 280.8 | 683 | 672 | 136.2 |
| B | 5 | 172 | 1314450 | 10958.53 | 647 | 634 | 119.9 |
| B | 0 | 189 | 67596 | 558.53 | 647 | 634 | 119.9 |
| B | 3 | 112 | 39489 | 324.09 | 647 | 634 | 119.9 |
| C | 15 | 214 | 220269 | 1455.14 | 662 | 670 | 150.9 |
| C | 0 | 10 | 144803 | 955.08 | 662 | 670 | 150.9 |
| C | 14 | 67 | 44986 | 293.65 | 662 | 670 | 150.9 |
| D | 8 | 195 | 1305725 | 8310.66 | 650 | 630 | 157.0 |
| D | 7 | 223 | 494121 | 3142.48 | 650 | 630 | 157.0 |
| D | 2 | 250 | 217839 | 1383.16 | 650 | 630 | 157.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
