| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_156T01_9000004928_34508cztM0_level2.evt | modeM0/AS1A05_156T01_9000004928_34508cztM0_level2_quad_clean.evt |
| Size (bytes) | 503,213,760 | 55,431,360 |
| Size | 479.9 MB | 52.9 MB |
| Events in quadrant A | 2,994,819 | 334,975 |
| Events in quadrant B | 4,002,748 | 331,242 |
| Events in quadrant C | 3,189,315 | 327,900 |
| Events in quadrant D | 4,688,680 | 307,303 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 108 | 0 |
| B | 0 | 108 | 0 |
| C | 0 | 108 | 0 |
| D | 0 | 108 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12130 | 3 |
| B | 0 | 15272 | 2 |
| C | 0 | 12564 | 2 |
| D | 0 | 17642 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 28 | 0 |
| B | 0 | 28 | 0 |
| C | 0 | 28 | 0 |
| D | 0 | 29 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5385 | 37 | 0.687094% |
| B | 5385 | 331 | 6.146704% |
| C | 5385 | 63 | 1.169916% |
| D | 5385 | 160 | 2.971216% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7388 | 5386 | 18 | 18 | 0.24% | 0.33% |  |
| B | 7388 | 5386 | 229 | 229 | 3.10% | 4.25% |  |
| C | 7388 | 5386 | 49 | 49 | 0.66% | 0.91% |  |
| D | 7388 | 5386 | 145 | 145 | 1.96% | 2.69% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 17 | 109474 | 772.49 | 710 | 696 | 140.8 |
| A | 9 | 143 | 82563 | 581.38 | 710 | 696 | 140.8 |
| A | 10 | 83 | 38536 | 268.72 | 710 | 696 | 140.8 |
| B | 5 | 172 | 901521 | 7014.3 | 679 | 664 | 128.4 |
| B | 4 | 232 | 158520 | 1229.11 | 679 | 664 | 128.4 |
| B | 0 | 229 | 104627 | 809.48 | 679 | 664 | 128.4 |
| C | 15 | 214 | 229575 | 1479.27 | 676 | 684 | 154.7 |
| C | 0 | 10 | 155501 | 1000.55 | 676 | 684 | 154.7 |
| C | 12 | 249 | 72163 | 461.95 | 676 | 684 | 154.7 |
| D | 8 | 195 | 1035572 | 6212.25 | 683 | 664 | 166.6 |
| D | 7 | 80 | 339119 | 2031.65 | 683 | 664 | 166.6 |
| D | 3 | 13 | 115425 | 688.87 | 683 | 664 | 166.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
