| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_156T01_9000004928_34511cztM0_level2.evt | modeM0/AS1A05_156T01_9000004928_34511cztM0_level2_quad_clean.evt |
| Size (bytes) | 390,542,400 | 66,147,840 |
| Size | 372.5 MB | 63.1 MB |
| Events in quadrant A | 2,487,410 | 418,631 |
| Events in quadrant B | 2,980,820 | 418,711 |
| Events in quadrant C | 2,786,518 | 419,886 |
| Events in quadrant D | 3,236,414 | 398,435 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 100 | 0 |
| B | 0 | 100 | 0 |
| C | 0 | 100 | 0 |
| D | 0 | 100 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10488 | 3 |
| B | 0 | 11980 | 2 |
| C | 0 | 11168 | 2 |
| D | 0 | 13031 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24 | 0 |
| B | 0 | 24 | 0 |
| C | 0 | 24 | 0 |
| D | 0 | 25 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4954 | 16 | 0.322971% |
| B | 4954 | 96 | 1.937828% |
| C | 4954 | 55 | 1.110214% |
| D | 4954 | 60 | 1.211143% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7046 | 4955 | 5 | 5 | 0.07% | 0.10% |  |
| B | 7046 | 4955 | 53 | 53 | 0.75% | 1.07% |  |
| C | 7046 | 4955 | 35 | 35 | 0.50% | 0.71% |  |
| D | 7046 | 4955 | 56 | 56 | 0.79% | 1.13% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 17 | 41264 | 334.1 | 610 | 598 | 121.7 |
| A | 10 | 83 | 39840 | 322.4 | 610 | 598 | 121.7 |
| A | 9 | 143 | 38091 | 308.03 | 610 | 598 | 121.7 |
| B | 5 | 172 | 308685 | 2719.08 | 603 | 589 | 113.3 |
| B | 0 | 229 | 121599 | 1067.96 | 603 | 589 | 113.3 |
| B | 0 | 189 | 57413 | 501.5 | 603 | 589 | 113.3 |
| C | 15 | 214 | 209994 | 1533.35 | 597 | 603 | 136.6 |
| C | 0 | 10 | 157004 | 1145.31 | 597 | 603 | 136.6 |
| C | 14 | 67 | 72754 | 528.35 | 597 | 603 | 136.6 |
| D | 8 | 195 | 509745 | 3524.45 | 594 | 579 | 144.5 |
| D | 13 | 249 | 80093 | 550.4 | 594 | 579 | 144.5 |
| D | 1 | 52 | 51899 | 355.24 | 594 | 579 | 144.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
