| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_005T01_9000004932_34526cztM0_level2.evt | modeM0/AS1A06_005T01_9000004932_34526cztM0_level2_quad_clean.evt |
| Size (bytes) | 530,812,800 | 94,806,720 |
| Size | 506.2 MB | 90.4 MB |
| Events in quadrant A | 2,506,337 | 662,365 |
| Events in quadrant B | 4,020,157 | 626,709 |
| Events in quadrant C | 2,758,009 | 652,072 |
| Events in quadrant D | 6,426,554 | 552,878 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 110 | 0 |
| B | 0 | 110 | 0 |
| C | 0 | 110 | 0 |
| D | 0 | 110 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11000 | 3 |
| B | 0 | 15389 | 2 |
| C | 0 | 11315 | 2 |
| D | 0 | 22767 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5376 | 8 | 0.148810% |
| B | 5376 | 516 | 9.598214% |
| C | 5376 | 21 | 0.390625% |
| D | 5376 | 1045 | 19.438244% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7379 | 5377 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7379 | 5377 | 405 | 405 | 5.49% | 7.53% |  |
| C | 7379 | 5377 | 10 | 10 | 0.14% | 0.19% |  |
| D | 7379 | 5377 | 959 | 959 | 13.00% | 17.84% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 37800 | 294.37 | 630 | 618 | 126.3 |
| A | 9 | 143 | 20907 | 160.63 | 630 | 618 | 126.3 |
| A | 13 | 6 | 14503 | 109.93 | 630 | 618 | 126.3 |
| B | 5 | 172 | 850353 | 7460.49 | 598 | 584 | 113.9 |
| B | 4 | 170 | 307994 | 2698.89 | 598 | 584 | 113.9 |
| B | 5 | 200 | 243302 | 2130.93 | 598 | 584 | 113.9 |
| C | 15 | 214 | 242222 | 1723.96 | 607 | 613 | 140.1 |
| C | 0 | 10 | 70572 | 499.18 | 607 | 613 | 140.1 |
| C | 14 | 67 | 62076 | 438.56 | 607 | 613 | 140.1 |
| D | 10 | 118 | 1559717 | 11686.47 | 554 | 539 | 133.4 |
| D | 7 | 80 | 1080246 | 8092.7 | 554 | 539 | 133.4 |
| D | 8 | 195 | 872283 | 6533.96 | 554 | 539 | 133.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
