| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_005T01_9000004932_34533cztM0_level2.evt | modeM0/AS1A06_005T01_9000004932_34533cztM0_level2_quad_clean.evt |
| Size (bytes) | 499,956,480 | 68,097,600 |
| Size | 476.8 MB | 64.9 MB |
| Events in quadrant A | 2,609,952 | 434,013 |
| Events in quadrant B | 3,292,081 | 432,174 |
| Events in quadrant C | 2,874,334 | 429,575 |
| Events in quadrant D | 5,990,644 | 379,765 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 24 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 112 | 0 |
| B | 0 | 112 | 0 |
| C | 0 | 112 | 0 |
| D | 0 | 112 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11333 | 3 |
| B | 0 | 13303 | 2 |
| C | 0 | 11659 | 2 |
| D | 0 | 21648 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5518 | 10 | 0.181225% |
| B | 5518 | 185 | 3.352664% |
| C | 5518 | 18 | 0.326205% |
| D | 5518 | 742 | 13.446901% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7161 | 5519 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7161 | 5519 | 127 | 127 | 1.77% | 2.30% |  |
| C | 7161 | 5519 | 9 | 9 | 0.13% | 0.16% |  |
| D | 7161 | 5519 | 623 | 623 | 8.70% | 11.29% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 143 | 50537 | 382.33 | 648 | 634 | 130.5 |
| A | 10 | 83 | 39437 | 297.29 | 648 | 634 | 130.5 |
| A | 13 | 6 | 12985 | 94.63 | 648 | 634 | 130.5 |
| B | 5 | 172 | 730358 | 5872.72 | 640 | 623 | 124.3 |
| B | 5 | 255 | 15792 | 122.08 | 640 | 623 | 124.3 |
| B | 12 | 111 | 15149 | 116.9 | 640 | 623 | 124.3 |
| C | 15 | 214 | 248825 | 1676.65 | 639 | 643 | 148.0 |
| C | 0 | 10 | 76439 | 512.06 | 639 | 643 | 148.0 |
| C | 14 | 67 | 49670 | 331.21 | 639 | 643 | 148.0 |
| D | 2 | 249 | 1351678 | 9098.48 | 605 | 586 | 148.5 |
| D | 8 | 195 | 807082 | 5431.08 | 605 | 586 | 148.5 |
| D | 12 | 17 | 584703 | 3933.54 | 605 | 586 | 148.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
