| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_167T01_9000004940_34566cztM0_level2.evt | modeM0/AS1A05_167T01_9000004940_34566cztM0_level2_quad_clean.evt |
| Size (bytes) | 460,756,800 | 68,918,400 |
| Size | 439.4 MB | 65.7 MB |
| Events in quadrant A | 2,630,480 | 440,901 |
| Events in quadrant B | 3,224,698 | 443,800 |
| Events in quadrant C | 2,786,145 | 438,128 |
| Events in quadrant D | 4,970,151 | 409,786 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 104 | 0 |
| B | 0 | 104 | 0 |
| C | 0 | 104 | 0 |
| D | 0 | 104 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 22 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10569 | 3 |
| B | 0 | 12496 | 2 |
| C | 0 | 10917 | 2 |
| D | 0 | 18306 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5049 | 10 | 0.198059% |
| B | 5049 | 166 | 3.287780% |
| C | 5049 | 25 | 0.495148% |
| D | 5049 | 394 | 7.803525% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7052 | 5050 | 6 | 6 | 0.09% | 0.12% |  |
| B | 7052 | 5050 | 102 | 102 | 1.45% | 2.02% |  |
| C | 7052 | 5050 | 17 | 17 | 0.24% | 0.34% |  |
| D | 7052 | 5050 | 311 | 311 | 4.41% | 6.16% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 40966 | 308.0 | 660 | 648 | 130.9 |
| A | 9 | 143 | 25279 | 188.16 | 660 | 648 | 130.9 |
| A | 13 | 6 | 11592 | 83.6 | 660 | 648 | 130.9 |
| B | 5 | 172 | 511728 | 4186.79 | 642 | 627 | 122.1 |
| B | 0 | 189 | 75193 | 610.82 | 642 | 627 | 122.1 |
| B | 0 | 229 | 37616 | 303.0 | 642 | 627 | 122.1 |
| C | 15 | 214 | 215895 | 1468.97 | 632 | 637 | 146.5 |
| C | 0 | 10 | 82540 | 558.92 | 632 | 637 | 146.5 |
| C | 14 | 67 | 16804 | 110.33 | 632 | 637 | 146.5 |
| D | 8 | 195 | 1318095 | 8580.86 | 625 | 609 | 153.5 |
| D | 7 | 80 | 823897 | 5362.12 | 625 | 609 | 153.5 |
| D | 2 | 250 | 166288 | 1079.08 | 625 | 609 | 153.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
