| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_078T01_9000004962_34686cztM0_level2.evt | modeM0/AS1T04_078T01_9000004962_34686cztM0_level2_quad_clean.evt |
| Size (bytes) | 262,128,960 | 21,268,800 |
| Size | 250.0 MB | 20.3 MB |
| Events in quadrant A | 1,374,799 | 113,795 |
| Events in quadrant B | 1,659,065 | 113,888 |
| Events in quadrant C | 1,647,011 | 111,695 |
| Events in quadrant D | 3,067,430 | 105,099 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5771 | 1 |
| B | 0 | 6654 | 1 |
| C | 0 | 6457 | 1 |
| D | 0 | 11114 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 18 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 56 | 0 |
| B | 0 | 56 | 0 |
| C | 0 | 56 | 0 |
| D | 0 | 56 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2780 | 14 | 0.503597% |
| B | 2780 | 88 | 3.165468% |
| C | 2780 | 55 | 1.978417% |
| D | 2780 | 265 | 9.532374% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 2780 | 2780 | 6 | 6 | 0.22% | 0.22% |  |
| B | 2780 | 2780 | 48 | 48 | 1.73% | 1.73% |  |
| C | 2780 | 2780 | 52 | 52 | 1.87% | 1.87% |  |
| D | 2780 | 2780 | 215 | 215 | 7.73% | 7.73% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 143 | 39930 | 578.28 | 333 | 327 | 68.5 |
| A | 10 | 83 | 24267 | 349.57 | 333 | 327 | 68.5 |
| A | 13 | 6 | 10798 | 152.9 | 333 | 327 | 68.5 |
| B | 5 | 255 | 192859 | 3043.66 | 325 | 317 | 63.3 |
| B | 5 | 172 | 108587 | 1711.51 | 325 | 317 | 63.3 |
| B | 0 | 218 | 19230 | 298.97 | 325 | 317 | 63.3 |
| C | 15 | 214 | 119409 | 1588.98 | 317 | 319 | 74.9 |
| C | 0 | 10 | 100514 | 1336.87 | 317 | 319 | 74.9 |
| C | 15 | 208 | 64435 | 855.48 | 317 | 319 | 74.9 |
| D | 8 | 195 | 878652 | 10258.27 | 311 | 304 | 85.6 |
| D | 7 | 38 | 461083 | 5381.46 | 311 | 304 | 85.6 |
| D | 2 | 120 | 176822 | 2061.56 | 311 | 304 | 85.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
