| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_048T04_9000004984cztM0_level2.fits | modeM0/AS1A10_048T04_9000004984cztM0_level2_quad_clean.evt |
| Size (bytes) | 468,673,920 | 320,592,960 |
| Size | 447.0 MB | 305.7 MB |
| Events in quadrant A | 2,913,108 | 1,700,829 |
| Events in quadrant B | 2,725,612 | 1,633,846 |
| Events in quadrant C | 2,892,264 | 1,641,082 |
| Events in quadrant D | 2,384,072 | 1,454,107 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 976 | 0 |
| B | 0 | 976 | 0 |
| C | 0 | 976 | 0 |
| D | 0 | 976 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 110511 | 0 |
| B | 0 | 129247 | 0 |
| C | 0 | 103084 | 0 |
| D | 0 | 156737 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 198 | 0 |
| B | 0 | 198 | 0 |
| C | 0 | 198 | 0 |
| D | 0 | 198 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 47751 | 352 | 0.737157% |
| B | 47751 | 3038 | 6.362170% |
| C | 47751 | 261 | 0.546585% |
| D | 47751 | 3415 | 7.151683% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 67562 | 47740 | 0 | 0 | 0.00% | 0.00% |  |
| B | 67562 | 47729 | 0 | 0 | 0.00% | 0.00% |  |
| C | 67562 | 47752 | 0 | 0 | 0.00% | 0.00% |  |
| D | 67562 | 47468 | 0 | 0 | 0.00% | 0.00% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 19 | 2355 | 8.9 | 761 | 717 | 184.1 |
| A | 7 | 110 | 2304 | 8.62 | 761 | 717 | 184.1 |
| A | 0 | 29 | 2242 | 8.28 | 761 | 717 | 184.1 |
| B | 2 | 9 | 2373 | 11.71 | 721 | 690 | 143.7 |
| B | 3 | 80 | 2141 | 10.1 | 721 | 690 | 143.7 |
| B | 2 | 8 | 1897 | 8.4 | 721 | 690 | 143.7 |
| C | 1 | 81 | 2359 | 8.44 | 764 | 718 | 194.5 |
| C | 1 | 80 | 2331 | 8.29 | 764 | 718 | 194.5 |
| C | 3 | 202 | 2284 | 8.05 | 764 | 718 | 194.5 |
| D | 6 | 67 | 1739 | 6.14 | 683 | 626 | 181.2 |
| D | 4 | 160 | 1727 | 6.08 | 683 | 626 | 181.2 |
| D | 7 | 3 | 1716 | 6.02 | 683 | 626 | 181.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
