| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_005T01_9000004992_34819cztM0_level2.evt | modeM0/AS1C07_005T01_9000004992_34819cztM0_level2_quad_clean.evt |
| Size (bytes) | 572,990,400 | 102,764,160 |
| Size | 546.4 MB | 98.0 MB |
| Events in quadrant A | 2,889,814 | 693,026 |
| Events in quadrant B | 6,579,164 | 655,167 |
| Events in quadrant C | 3,132,477 | 693,231 |
| Events in quadrant D | 4,347,575 | 653,472 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12398 | 3 |
| B | 0 | 23629 | 2 |
| C | 0 | 12861 | 2 |
| D | 0 | 16999 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5968 | 10 | 0.167560% |
| B | 5968 | 857 | 14.359920% |
| C | 5968 | 50 | 0.837802% |
| D | 5968 | 201 | 3.367962% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7282 | 5969 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7282 | 5969 | 660 | 660 | 9.06% | 11.06% |  |
| C | 7282 | 5969 | 30 | 30 | 0.41% | 0.50% |  |
| D | 7282 | 5969 | 203 | 203 | 2.79% | 3.40% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 149041 | 1070.68 | 684 | 669 | 138.6 |
| A | 10 | 83 | 54717 | 390.02 | 684 | 669 | 138.6 |
| A | 15 | 223 | 24714 | 173.51 | 684 | 669 | 138.6 |
| B | 4 | 251 | 3691375 | 29519.21 | 655 | 638 | 125.0 |
| B | 5 | 172 | 101466 | 806.44 | 655 | 638 | 125.0 |
| B | 10 | 245 | 81319 | 645.3 | 655 | 638 | 125.0 |
| C | 15 | 214 | 276105 | 1791.86 | 661 | 663 | 153.7 |
| C | 0 | 10 | 133477 | 864.01 | 661 | 663 | 153.7 |
| C | 14 | 67 | 88217 | 569.57 | 661 | 663 | 153.7 |
| D | 8 | 195 | 766450 | 4765.97 | 658 | 638 | 160.7 |
| D | 12 | 233 | 363470 | 2258.06 | 658 | 638 | 160.7 |
| D | 14 | 52 | 165535 | 1026.22 | 658 | 638 | 160.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
