| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_005T01_9000004992_34862cztM0_level2.evt | modeM0/AS1C07_005T01_9000004992_34862cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,321,908,480 | 73,264,320 |
| Size | 1.2 GB | 69.9 MB |
| Events in quadrant A | 13,012,488 | 341,964 |
| Events in quadrant B | 15,435,740 | 252,748 |
| Events in quadrant C | 3,666,178 | 638,033 |
| Events in quadrant D | 7,517,757 | 560,071 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 42736 | 3 |
| B | 0 | 49940 | 2 |
| C | 0 | 14432 | 2 |
| D | 0 | 26534 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6026 | 4693 | 77.879190% |
| B | 6026 | 6010 | 99.734484% |
| C | 6026 | 136 | 2.256887% |
| D | 6026 | 1157 | 19.200133% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7338 | 6027 | 4435 | 4435 | 60.44% | 73.59% |  |
| B | 7337 | 6025 | 5886 | 5886 | 80.22% | 97.69% |  |
| C | 7338 | 6027 | 115 | 115 | 1.57% | 1.91% |  |
| D | 7338 | 6027 | 1143 | 1143 | 15.58% | 18.96% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 11264843 | 132206.74 | 421 | 413 | 85.2 |
| A | 15 | 237 | 65541 | 764.38 | 421 | 413 | 85.2 |
| A | 10 | 83 | 39932 | 463.82 | 421 | 413 | 85.2 |
| B | 5 | 31 | 6372532 | 109661.93 | 298 | 290 | 58.1 |
| B | 5 | 15 | 5807723 | 99941.95 | 298 | 290 | 58.1 |
| B | 5 | 14 | 1644910 | 28302.79 | 298 | 290 | 58.1 |
| C | 0 | 207 | 464311 | 3009.26 | 665 | 668 | 154.1 |
| C | 15 | 214 | 275085 | 1781.09 | 665 | 668 | 154.1 |
| C | 0 | 10 | 211456 | 1368.11 | 665 | 668 | 154.1 |
| D | 12 | 227 | 3184768 | 20498.75 | 634 | 618 | 155.3 |
| D | 8 | 195 | 513279 | 3300.38 | 634 | 618 | 155.3 |
| D | 2 | 249 | 288454 | 1853.01 | 634 | 618 | 155.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
