| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_005T01_9000004992_34872cztM0_level2.evt | modeM0/AS1C07_005T01_9000004992_34872cztM0_level2_quad_clean.evt |
| Size (bytes) | 413,228,160 | 76,213,440 |
| Size | 394.1 MB | 72.7 MB |
| Events in quadrant A | 2,549,159 | 501,605 |
| Events in quadrant B | 3,150,178 | 506,615 |
| Events in quadrant C | 2,674,055 | 499,908 |
| Events in quadrant D | 3,809,234 | 456,826 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 32 | 0 |
| B | 0 | 32 | 0 |
| C | 0 | 32 | 0 |
| D | 0 | 33 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10427 | 3 |
| B | 0 | 12365 | 2 |
| C | 0 | 10455 | 2 |
| D | 0 | 14460 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 102 | 0 |
| B | 0 | 102 | 0 |
| C | 0 | 102 | 0 |
| D | 0 | 102 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4879 | 54 | 1.106784% |
| B | 4879 | 148 | 3.033408% |
| C | 4879 | 33 | 0.676368% |
| D | 4879 | 215 | 4.406641% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7032 | 4879 | 42 | 42 | 0.60% | 0.86% |  |
| B | 7032 | 4879 | 89 | 89 | 1.27% | 1.82% |  |
| C | 7032 | 4880 | 23 | 23 | 0.33% | 0.47% |  |
| D | 7032 | 4880 | 206 | 206 | 2.93% | 4.22% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 169 | 103095 | 864.73 | 602 | 593 | 118.5 |
| A | 10 | 83 | 48425 | 403.52 | 602 | 593 | 118.5 |
| A | 15 | 237 | 42786 | 355.95 | 602 | 593 | 118.5 |
| B | 5 | 172 | 468022 | 4236.42 | 598 | 585 | 110.3 |
| B | 0 | 190 | 152074 | 1372.96 | 598 | 585 | 110.3 |
| B | 5 | 31 | 77157 | 693.98 | 598 | 585 | 110.3 |
| C | 15 | 214 | 208410 | 1526.15 | 594 | 599 | 136.2 |
| C | 0 | 10 | 116215 | 849.08 | 594 | 599 | 136.2 |
| C | 14 | 67 | 14192 | 99.83 | 594 | 599 | 136.2 |
| D | 13 | 249 | 502913 | 3621.25 | 580 | 566 | 138.7 |
| D | 8 | 195 | 478614 | 3446.09 | 580 | 566 | 138.7 |
| D | 2 | 31 | 140535 | 1008.99 | 580 | 566 | 138.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
