| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_047T09_9000005010_34962cztM0_level2.evt | modeM0/AS1A11_047T09_9000005010_34962cztM0_level2_quad_clean.evt |
| Size (bytes) | 486,645,120 | 55,149,120 |
| Size | 464.1 MB | 52.6 MB |
| Events in quadrant A | 2,736,161 | 328,968 |
| Events in quadrant B | 3,682,203 | 325,669 |
| Events in quadrant C | 3,043,771 | 325,944 |
| Events in quadrant D | 4,888,096 | 289,159 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11903 | 3 |
| B | 0 | 14671 | 2 |
| C | 0 | 12471 | 2 |
| D | 0 | 18411 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25 | 0 |
| B | 0 | 25 | 0 |
| C | 0 | 25 | 0 |
| D | 0 | 26 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5716 | 25 | 0.437369% |
| B | 5716 | 286 | 5.003499% |
| C | 5716 | 40 | 0.699790% |
| D | 5716 | 599 | 10.479356% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7179 | 5717 | 16 | 16 | 0.22% | 0.28% |  |
| B | 7179 | 5717 | 213 | 213 | 2.97% | 3.73% |  |
| C | 7179 | 5717 | 33 | 33 | 0.46% | 0.58% |  |
| D | 7179 | 5717 | 550 | 550 | 7.66% | 9.62% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 223 | 77923 | 579.87 | 657 | 643 | 133.3 |
| A | 10 | 83 | 72210 | 537.0 | 657 | 643 | 133.3 |
| A | 9 | 143 | 24624 | 179.94 | 657 | 643 | 133.3 |
| B | 5 | 172 | 930453 | 7382.49 | 643 | 626 | 126.0 |
| B | 0 | 190 | 91364 | 720.43 | 643 | 626 | 126.0 |
| B | 10 | 245 | 80589 | 634.88 | 643 | 626 | 126.0 |
| C | 15 | 214 | 241735 | 1591.88 | 640 | 642 | 151.5 |
| C | 12 | 250 | 137058 | 900.72 | 640 | 642 | 151.5 |
| C | 0 | 10 | 132212 | 868.72 | 640 | 642 | 151.5 |
| D | 8 | 195 | 730912 | 4831.91 | 609 | 592 | 151.1 |
| D | 10 | 118 | 601930 | 3978.54 | 609 | 592 | 151.1 |
| D | 1 | 52 | 564214 | 3729.01 | 609 | 592 | 151.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
