| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_057T01_9000005022_35058cztM0_level2.evt | modeM0/AS1A10_057T01_9000005022_35058cztM0_level2_quad_clean.evt |
| Size (bytes) | 486,195,840 | 93,415,680 |
| Size | 463.7 MB | 89.1 MB |
| Events in quadrant A | 2,717,117 | 646,988 |
| Events in quadrant B | 3,285,972 | 630,069 |
| Events in quadrant C | 3,407,501 | 612,768 |
| Events in quadrant D | 4,958,387 | 571,612 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11314 | 3 |
| B | 0 | 13017 | 2 |
| C | 0 | 13265 | 2 |
| D | 0 | 18495 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 108 | 0 |
| B | 0 | 108 | 0 |
| C | 0 | 108 | 0 |
| D | 0 | 108 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5243 | 7 | 0.133511% |
| B | 5243 | 217 | 4.138852% |
| C | 5243 | 110 | 2.098035% |
| D | 5243 | 339 | 6.465764% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7247 | 5244 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7247 | 5244 | 97 | 97 | 1.34% | 1.85% |  |
| C | 7247 | 5244 | 114 | 114 | 1.57% | 2.17% |  |
| D | 7247 | 5244 | 331 | 331 | 4.57% | 6.31% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 66938 | 501.38 | 671 | 658 | 132.2 |
| A | 9 | 143 | 31034 | 229.78 | 671 | 658 | 132.2 |
| A | 13 | 6 | 15068 | 109.0 | 671 | 658 | 132.2 |
| B | 5 | 172 | 352412 | 2872.48 | 650 | 633 | 122.5 |
| B | 0 | 190 | 323166 | 2633.67 | 650 | 633 | 122.5 |
| B | 4 | 232 | 18886 | 149.05 | 650 | 633 | 122.5 |
| C | 1 | 23 | 612224 | 4160.09 | 641 | 647 | 147.0 |
| C | 15 | 214 | 218270 | 1480.32 | 641 | 647 | 147.0 |
| C | 0 | 10 | 52035 | 349.55 | 641 | 647 | 147.0 |
| D | 8 | 195 | 1099774 | 7142.08 | 638 | 622 | 153.9 |
| D | 1 | 47 | 392087 | 2543.66 | 638 | 622 | 153.9 |
| D | 10 | 118 | 282965 | 1834.61 | 638 | 622 | 153.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
